UTD1025DL UNI-T
Виробник: UNI-T
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 25MHz; LCD TFT 3,5"; Ch: 2; 250Msps; 12kpts
Band: 25MHz
Rise time: ≤14ns
AC voltage measuring range: 400mV; 4V; 40V; 400V
AC voltage measuring accuracy: ±(1.2% + 5 digit)
DC voltage measuring range: 400mV; 4V; 40V; 400V
DC voltage measuring accuracy: ±(1.2% + 5 digit)
AC current measuring range: 0.4mA; 4mA; 40mA; 4A
DC current measuring range: 0.4mA; 4mA; 40mA; 4A
Number of channels: 2
Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; resistance
Power supply: mains power supply; rechargeable battery Li-Ion 7,4V 3600mAh x1
Dimensions: 199x118x49mm
Measuring instrument features: automatic measurement of many parameters
Standard equipment: current shunt; mains adapter; mains cable; test leads; test probe x1; USB cable
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,4V 3600mAh x1
Interface: USB mini
Sampling: 250Msps
Input sensitivity: 5mV/div...20V/div
Time base: 10n...50s/div
Resistance measuring range: 0.4kΩ; 4kΩ; 40kΩ; 400kΩ; 4MΩ; 40MΩ
Capacitance measuring range: 51.2nF; 512nF; 5.12µF; 51.2µF; 100µF
Memory record length: 12kpts
Display parameters: (3999)
Capacitance measuring accuracy: ±(3%+ 5 digit)
Resistance measuring accuracy: ±(1.2%+5 digit); ±(1.5%+5 digit)@(40MΩ)
Kind of display used: LCD TFT 3,5"
Display resolution: 320x240
Type of oscilloscope: handheld oscilloscope
Trigger: falling-edge; impulse width; rising-edge; slope; video signal
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 25MHz; LCD TFT 3,5"; Ch: 2; 250Msps; 12kpts
Band: 25MHz
Rise time: ≤14ns
AC voltage measuring range: 400mV; 4V; 40V; 400V
AC voltage measuring accuracy: ±(1.2% + 5 digit)
DC voltage measuring range: 400mV; 4V; 40V; 400V
DC voltage measuring accuracy: ±(1.2% + 5 digit)
AC current measuring range: 0.4mA; 4mA; 40mA; 4A
DC current measuring range: 0.4mA; 4mA; 40mA; 4A
Number of channels: 2
Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; resistance
Power supply: mains power supply; rechargeable battery Li-Ion 7,4V 3600mAh x1
Dimensions: 199x118x49mm
Measuring instrument features: automatic measurement of many parameters
Standard equipment: current shunt; mains adapter; mains cable; test leads; test probe x1; USB cable
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,4V 3600mAh x1
Interface: USB mini
Sampling: 250Msps
Input sensitivity: 5mV/div...20V/div
Time base: 10n...50s/div
Resistance measuring range: 0.4kΩ; 4kΩ; 40kΩ; 400kΩ; 4MΩ; 40MΩ
Capacitance measuring range: 51.2nF; 512nF; 5.12µF; 51.2µF; 100µF
Memory record length: 12kpts
Display parameters: (3999)
Capacitance measuring accuracy: ±(3%+ 5 digit)
Resistance measuring accuracy: ±(1.2%+5 digit); ±(1.5%+5 digit)@(40MΩ)
Kind of display used: LCD TFT 3,5"
Display resolution: 320x240
Type of oscilloscope: handheld oscilloscope
Trigger: falling-edge; impulse width; rising-edge; slope; video signal
на замовлення 3 шт:
термін постачання 21-30 дні (днів)
Кількість | Ціна без ПДВ |
---|---|
1+ | 26329.94 грн |
Відгуки про товар
Написати відгук
Технічний опис UTD1025DL UNI-T
Category: Portable Oscilloscopes, Scopemeters, Description: Handheld oscilloscope; 25MHz; LCD TFT 3,5"; Ch: 2; 250Msps; 12kpts, Band: 25MHz, Rise time: ≤14ns, AC voltage measuring range: 400mV; 4V; 40V; 400V, AC voltage measuring accuracy: ±(1.2% + 5 digit), DC voltage measuring range: 400mV; 4V; 40V; 400V, DC voltage measuring accuracy: ±(1.2% + 5 digit), AC current measuring range: 0.4mA; 4mA; 40mA; 4A, DC current measuring range: 0.4mA; 4mA; 40mA; 4A, Number of channels: 2, Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; resistance, Power supply: mains power supply; rechargeable battery Li-Ion 7,4V 3600mAh x1, Dimensions: 199x118x49mm, Measuring instrument features: automatic measurement of many parameters, Standard equipment: current shunt; mains adapter; mains cable; test leads; test probe x1; USB cable, Battery/ rechargeable battery: rechargeable battery Li-Ion 7,4V 3600mAh x1, Interface: USB mini, Sampling: 250Msps, Input sensitivity: 5mV/div...20V/div, Time base: 10n...50s/div, Resistance measuring range: 0.4kΩ; 4kΩ; 40kΩ; 400kΩ; 4MΩ; 40MΩ, Capacitance measuring range: 51.2nF; 512nF; 5.12µF; 51.2µF; 100µF, Memory record length: 12kpts, Display parameters: (3999), Capacitance measuring accuracy: ±(3%+ 5 digit), Resistance measuring accuracy: ±(1.2%+5 digit); ±(1.5%+5 digit)@(40MΩ), Kind of display used: LCD TFT 3,5", Display resolution: 320x240, Type of oscilloscope: handheld oscilloscope, Trigger: falling-edge; impulse width; rising-edge; slope; video signal, кількість в упаковці: 1 шт.
Інші пропозиції UTD1025DL за ціною від 28948.59 грн до 31595.92 грн
Фото | Назва | Виробник | Інформація |
Доступність |
Ціна без ПДВ | ||||||
---|---|---|---|---|---|---|---|---|---|---|---|
+1 |
UTD1025DL | Виробник : UNI-T |
Category: Portable Oscilloscopes, Scopemeters Description: Handheld oscilloscope; 25MHz; LCD TFT 3,5"; Ch: 2; 250Msps; 12kpts Band: 25MHz Rise time: ≤14ns AC voltage measuring range: 400mV; 4V; 40V; 400V AC voltage measuring accuracy: ±(1.2% + 5 digit) DC voltage measuring range: 400mV; 4V; 40V; 400V DC voltage measuring accuracy: ±(1.2% + 5 digit) AC current measuring range: 0.4mA; 4mA; 40mA; 4A DC current measuring range: 0.4mA; 4mA; 40mA; 4A Number of channels: 2 Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; resistance Power supply: mains power supply; rechargeable battery Li-Ion 7,4V 3600mAh x1 Dimensions: 199x118x49mm Measuring instrument features: automatic measurement of many parameters Standard equipment: current shunt; mains adapter; mains cable; test leads; test probe x1; USB cable Battery/ rechargeable battery: rechargeable battery Li-Ion 7,4V 3600mAh x1 Interface: USB mini Sampling: 250Msps Input sensitivity: 5mV/div...20V/div Time base: 10n...50s/div Resistance measuring range: 0.4kΩ; 4kΩ; 40kΩ; 400kΩ; 4MΩ; 40MΩ Capacitance measuring range: 51.2nF; 512nF; 5.12µF; 51.2µF; 100µF Memory record length: 12kpts Display parameters: (3999) Capacitance measuring accuracy: ±(3%+ 5 digit) Resistance measuring accuracy: ±(1.2%+5 digit); ±(1.5%+5 digit)@(40MΩ) Kind of display used: LCD TFT 3,5" Display resolution: 320x240 Type of oscilloscope: handheld oscilloscope Trigger: falling-edge; impulse width; rising-edge; slope; video signal кількість в упаковці: 1 шт |
на замовлення 3 шт: термін постачання 14-21 дні (днів) |
|
