PCZ1V470MCL1GS Nichicon
Виробник: Nichicon
Description: CAPACITOR
Tolerance: ±20%
Packaging: Tape & Reel (TR)
Package / Case: Radial, Can - SMD
Size / Dimension: 0.315" Dia (8.00mm)
Mounting Type: Surface Mount
Type: Polymer
Operating Temperature: -55°C ~ 150°C
Applications: Automotive
Ratings: AEC-Q200
ESR (Equivalent Series Resistance): 44mOhm
Lifetime @ Temp.: 2000 Hrs @ 150°C
Surface Mount Land Size: 0.327" L x 0.327" W (8.30mm x 8.30mm)
Height - Seated (Max): 0.295" (7.50mm)
Capacitance: 47 µF
Voltage - Rated: 35 V
Ripple Current @ Low Frequency: 30 mA @ 120 Hz
Ripple Current @ High Frequency: 600 mA @ 100 kHz
Description: CAPACITOR
Tolerance: ±20%
Packaging: Tape & Reel (TR)
Package / Case: Radial, Can - SMD
Size / Dimension: 0.315" Dia (8.00mm)
Mounting Type: Surface Mount
Type: Polymer
Operating Temperature: -55°C ~ 150°C
Applications: Automotive
Ratings: AEC-Q200
ESR (Equivalent Series Resistance): 44mOhm
Lifetime @ Temp.: 2000 Hrs @ 150°C
Surface Mount Land Size: 0.327" L x 0.327" W (8.30mm x 8.30mm)
Height - Seated (Max): 0.295" (7.50mm)
Capacitance: 47 µF
Voltage - Rated: 35 V
Ripple Current @ Low Frequency: 30 mA @ 120 Hz
Ripple Current @ High Frequency: 600 mA @ 100 kHz
на замовлення 2000 шт:
термін постачання 21-31 дні (днів)
| Кількість | Ціна без ПДВ |
|---|---|
| 1000+ | 55.1 грн |
| 2000+ | 51.17 грн |
Відгуки про товар
Написати відгук
Технічний опис PCZ1V470MCL1GS Nichicon
Description: CAPACITOR, Tolerance: ±20%, Packaging: Tape & Reel (TR), Package / Case: Radial, Can - SMD, Size / Dimension: 0.315" Dia (8.00mm), Mounting Type: Surface Mount, Type: Polymer, Operating Temperature: -55°C ~ 150°C, Applications: Automotive, Ratings: AEC-Q200, ESR (Equivalent Series Resistance): 44mOhm, Lifetime @ Temp.: 2000 Hrs @ 150°C, Surface Mount Land Size: 0.327" L x 0.327" W (8.30mm x 8.30mm), Height - Seated (Max): 0.295" (7.50mm), Capacitance: 47 µF, Voltage - Rated: 35 V, Ripple Current @ Low Frequency: 30 mA @ 120 Hz, Ripple Current @ High Frequency: 600 mA @ 100 kHz.
Інші пропозиції PCZ1V470MCL1GS за ціною від 49.45 грн до 145.66 грн
| Фото | Назва | Виробник | Інформація |
Доступність |
Ціна без ПДВ | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
PCZ1V470MCL1GS | Виробник : Nichicon |
Description: CAPACITOR Tolerance: ±20% Packaging: Cut Tape (CT) Package / Case: Radial, Can - SMD Size / Dimension: 0.315" Dia (8.00mm) Mounting Type: Surface Mount Type: Polymer Operating Temperature: -55°C ~ 150°C Applications: Automotive Ratings: AEC-Q200 ESR (Equivalent Series Resistance): 44mOhm Lifetime @ Temp.: 2000 Hrs @ 150°C Surface Mount Land Size: 0.327" L x 0.327" W (8.30mm x 8.30mm) Height - Seated (Max): 0.295" (7.50mm) Capacitance: 47 µF Voltage - Rated: 35 V Ripple Current @ Low Frequency: 30 mA @ 120 Hz Ripple Current @ High Frequency: 600 mA @ 100 kHz |
на замовлення 2000 шт: термін постачання 21-31 дні (днів) |
|
||||||||||||||||
 |
PCZ1V470MCL1GS | Виробник : Nichicon |
 Aluminium Organic Polymer Capacitors 35V 47uF 20% AEC-Q200 Polymer Chip Type |
на замовлення 1984 шт: термін постачання 21-30 дні (днів) |
|
||||||||||||||||
| PCZ1V470MCL1GS | Виробник : Nichicon | Cap Aluminum Polymer 47uF 35VDC 20% (8 X 7mm) SMD 0.044 Ohm 600mA 2000h 150C Automotive T/R |
на замовлення 1000 шт: термін постачання 21-31 дні (днів) |
