P 1403 PEAKTECH
Виробник: PEAKTECH
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 50MHz; 500Msps; 10kpts; automatic
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT
Kind of display used: LCD TFT 7"
Standard equipment: mains cable; oscilloscope probe x2; USB cable
Body dimensions: 301x152x70mm
Operating temperature: 0...40°C
Max. input voltage: 400V
Plug variant: EU
Band: 50MHz
Rise time: ≤7ns
Input sensitivity: 5mV/div...5V/div
Time base: 5n...1ks/div
Software: included
Memory record length: 10kpts
Supply voltage: 100...240V AC
Power consumption: 15W
Interface: USB
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/20pF
Sampling: 500Msps
Type of oscilloscope: digital
Trigger: alternate; falling-edge; rising-edge; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Horizontal accuracy: ±3%
Trigger modes: automatic
Trigger source: CH1; CH2
Trigger coupling: DC
Kind of oscilloscope: DSO
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 50MHz; 500Msps; 10kpts; automatic
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT
Kind of display used: LCD TFT 7"
Standard equipment: mains cable; oscilloscope probe x2; USB cable
Body dimensions: 301x152x70mm
Operating temperature: 0...40°C
Max. input voltage: 400V
Plug variant: EU
Band: 50MHz
Rise time: ≤7ns
Input sensitivity: 5mV/div...5V/div
Time base: 5n...1ks/div
Software: included
Memory record length: 10kpts
Supply voltage: 100...240V AC
Power consumption: 15W
Interface: USB
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/20pF
Sampling: 500Msps
Type of oscilloscope: digital
Trigger: alternate; falling-edge; rising-edge; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Horizontal accuracy: ±3%
Trigger modes: automatic
Trigger source: CH1; CH2
Trigger coupling: DC
Kind of oscilloscope: DSO
на замовлення 6 шт:
термін постачання 21-30 дні (днів)
Кількість | Ціна без ПДВ |
---|---|
1+ | 16202.73 грн |
Відгуки про товар
Написати відгук
Технічний опис P 1403 PEAKTECH
Category: Digital Oscilloscopes, Description: Oscilloscope: digital; DSO; Ch: 2; 50MHz; 500Msps; 10kpts; automatic, Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT, Kind of display used: LCD TFT 7", Standard equipment: mains cable; oscilloscope probe x2; USB cable, Body dimensions: 301x152x70mm, Operating temperature: 0...40°C, Max. input voltage: 400V, Plug variant: EU, Band: 50MHz, Rise time: ≤7ns, Input sensitivity: 5mV/div...5V/div, Time base: 5n...1ks/div, Software: included, Memory record length: 10kpts, Supply voltage: 100...240V AC, Power consumption: 15W, Interface: USB, Number of channels: 2, Display resolution: 800x480, Input impedance: 1MΩ/20pF, Sampling: 500Msps, Type of oscilloscope: digital, Trigger: alternate; falling-edge; rising-edge; video signal, Input coupling: AC, DC, GND, Vertical resolution: 8bit, Horizontal accuracy: ±3%, Trigger modes: automatic, Trigger source: CH1; CH2, Trigger coupling: DC, Kind of oscilloscope: DSO, кількість в упаковці: 1 шт.
Інші пропозиції P 1403 за ціною від 19443.27 грн до 19443.27 грн
