NP05-1A66-500-213 MEDER
![np-metal.pdf](/images/adobe-acrobat.png)
Category: Reed Electromagnetic Relays
Description: Relay: reed switch; SPST-NO; Ucoil: 5VDC; 1.25A; max.200VDC; 10W
Contacts configuration: SPST-NO
Mounting: PCB
Terminal pitch: 5.08mm
Operating temperature: -20...85°C
Contact resistance: 0.15Ω
Min. insulation resistance: 10GΩ
Coil resistance: 500Ω
Body dimensions: 22x10.2x10.1mm
Type of relay: reed switch
Relay variant: shielded
Relay series: NP
Rated coil voltage: 5V DC
Coil power consumption: 50mW
Operate time: 0.5ms
Release time: 0.1ms
Switched voltage: max. 200V AC; max. 200V DC
Contact current max.: 1.25A
Switching capacity: 10W
на замовлення 88 шт:
термін постачання 21-30 дні (днів)
Кількість | Ціна без ПДВ |
---|---|
2+ | 263.14 грн |
5+ | 162.66 грн |
14+ | 153.51 грн |
Відгуки про товар
Написати відгук
Технічний опис NP05-1A66-500-213 MEDER
Category: Reed Electromagnetic Relays, Description: Relay: reed switch; SPST-NO; Ucoil: 5VDC; 1.25A; max.200VDC; 10W, Contacts configuration: SPST-NO, Mounting: PCB, Terminal pitch: 5.08mm, Operating temperature: -20...85°C, Contact resistance: 0.15Ω, Min. insulation resistance: 10GΩ, Coil resistance: 500Ω, Body dimensions: 22x10.2x10.1mm, Type of relay: reed switch, Relay variant: shielded, Relay series: NP, Rated coil voltage: 5V DC, Coil power consumption: 50mW, Operate time: 0.5ms, Release time: 0.1ms, Switched voltage: max. 200V AC; max. 200V DC, Contact current max.: 1.25A, Switching capacity: 10W, кількість в упаковці: 1 шт.
Інші пропозиції NP05-1A66-500-213 за ціною від 177.45 грн до 315.77 грн
Фото | Назва | Виробник | Інформація |
Доступність |
Ціна без ПДВ | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
NP05-1A66-500-213 | Виробник : MEDER |
![]() Description: Relay: reed switch; SPST-NO; Ucoil: 5VDC; 1.25A; max.200VDC; 10W Contacts configuration: SPST-NO Mounting: PCB Terminal pitch: 5.08mm Operating temperature: -20...85°C Contact resistance: 0.15Ω Min. insulation resistance: 10GΩ Coil resistance: 500Ω Body dimensions: 22x10.2x10.1mm Type of relay: reed switch Relay variant: shielded Relay series: NP Rated coil voltage: 5V DC Coil power consumption: 50mW Operate time: 0.5ms Release time: 0.1ms Switched voltage: max. 200V AC; max. 200V DC Contact current max.: 1.25A Switching capacity: 10W кількість в упаковці: 1 шт |
на замовлення 88 шт: термін постачання 14-21 дні (днів) |
|
||||||||||
![]() |
NP05-1A66-500-213 | Виробник : MEDER electronic (Standex) |
![]() |
товар відсутній |
