MSOX2014A KEYSIGHT TECHNOLOGIES

Category: Digital Oscilloscopes, Description: Oscilloscope: mixed signal; Ch: 4; 100MHz; 2Gsps; 100kpts/ch, Interface: Ethernet; IEEE-488; RS232; USB, Kind of output connector: D-Sub female socket; GPIB socket; RJ45 socket; USB A socket, Manufacturer series: InfiniiVision 2000 X-SERIES MSO, Display resolution: 800x480, Input impedance: 1MΩ/11pF, Standard equipment: calibration certificate; CD with documentation; mains cable; oscilloscope probe (1 per channel), Measuring instrument features: 2 waveforms recording; 8 digital channels; 10 sets memory; automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplication and FFT; multilanguage menu; X-Y, ROLL operation mode, Sampling: 2Gsps, Type of oscilloscope: mixed signal, Trigger: falling-edge; impulse width; rising-edge; video signal, Input coupling: AC, DC, Vertical resolution: 8bit, Trigger modes: automatic; normal; single, Trigger coupling: AC; DC; highpass; lowpass, Max. input voltage: 300V, Plug variant: EU, Information: Products are intended for professional and industrial use only, and are not suitable for consumer or household use., Band: 100MHz, Rise time: ≤3.5ns, Input sensitivity: 1mV/div...5V/div, Time base: 5n...50s/div, Memory record length: 100kpts/ch, Kind of display used: colour; LCD 8,5", Supply voltage: 100...240V AC, Body dimensions: 381x204x142mm, Number of channels: 4.
