FTSH-110-01-F-DV-K-A-P-TR Samtec Inc.
![ftsh_smt.pdf](/images/adobe-acrobat.png)
Description: CONN HEADER SMD 20POS 1.27MM
Features: Board Guide, Keying Shroud, Pick and Place
Packaging: Tape & Reel (TR)
Connector Type: Header, Cuttable
Current Rating (Amps): 3.4A per Contact
Mounting Type: Surface Mount
Number of Positions: 20
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 3.00µin (0.076µm)
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Square
Insulation Height: 0.099" (2.51mm)
Shrouding: Shrouded
Insulation Material: Liquid Crystal Polymer (LCP)
Row Spacing - Mating: 0.050" (1.27mm)
Contact Length - Mating: 0.120" (3.05mm)
на замовлення 400 шт:
термін постачання 21-31 дні (днів)
Кількість | Ціна без ПДВ |
---|---|
400+ | 232.19 грн |
Відгуки про товар
Написати відгук
Технічний опис FTSH-110-01-F-DV-K-A-P-TR Samtec Inc.
Description: CONN HEADER SMD 20POS 1.27MM, Features: Board Guide, Keying Shroud, Pick and Place, Packaging: Tape & Reel (TR), Connector Type: Header, Cuttable, Current Rating (Amps): 3.4A per Contact, Mounting Type: Surface Mount, Number of Positions: 20, Number of Rows: 2, Style: Board to Board or Cable, Operating Temperature: -55°C ~ 125°C, Contact Type: Male Pin, Fastening Type: Push-Pull, Number of Positions Loaded: All, Termination: Solder, Material Flammability Rating: UL94 V-0, Contact Material: Phosphor Bronze, Insulation Color: Black, Pitch - Mating: 0.050" (1.27mm), Contact Finish - Mating: Gold, Contact Finish Thickness - Mating: 3.00µin (0.076µm), Contact Finish - Post: Tin, Part Status: Active, Contact Shape: Square, Insulation Height: 0.099" (2.51mm), Shrouding: Shrouded, Insulation Material: Liquid Crystal Polymer (LCP), Row Spacing - Mating: 0.050" (1.27mm), Contact Length - Mating: 0.120" (3.05mm).
Інші пропозиції FTSH-110-01-F-DV-K-A-P-TR за ціною від 343.26 грн до 450.1 грн
Фото | Назва | Виробник | Інформація |
Доступність |
Ціна без ПДВ | ||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
FTSH-110-01-F-DV-K-A-P-TR | Виробник : Samtec Inc. |
![]() Features: Board Guide, Keying Shroud, Pick and Place Packaging: Cut Tape (CT) Connector Type: Header, Cuttable Current Rating (Amps): 3.4A per Contact Mounting Type: Surface Mount Number of Positions: 20 Number of Rows: 2 Style: Board to Board or Cable Operating Temperature: -55°C ~ 125°C Contact Type: Male Pin Fastening Type: Push-Pull Number of Positions Loaded: All Termination: Solder Material Flammability Rating: UL94 V-0 Contact Material: Phosphor Bronze Insulation Color: Black Pitch - Mating: 0.050" (1.27mm) Contact Finish - Mating: Gold Contact Finish Thickness - Mating: 3.00µin (0.076µm) Contact Finish - Post: Tin Part Status: Active Contact Shape: Square Insulation Height: 0.099" (2.51mm) Shrouding: Shrouded Insulation Material: Liquid Crystal Polymer (LCP) Row Spacing - Mating: 0.050" (1.27mm) Contact Length - Mating: 0.120" (3.05mm) |
на замовлення 400 шт: термін постачання 21-31 дні (днів) |
|
|||||||||
![]() |
FTSH-110-01-F-DV-K-A-P-TR | Виробник : Samtec |
![]() |
товар відсутній |
|||||||||
![]() |
FTSH-110-01-F-DV-K-A-P-TR | Виробник : Samtec |
![]() |
товар відсутній |
