Технічний опис FK4B01120L1 Panasonic
Description: MOSFET N-CH 12V 3.9A ULGA004, Packaging: Tape & Reel (TR), Package / Case: 4-XFLGA, CSP, Mounting Type: Surface Mount, Operating Temperature: -40°C ~ 85°C (TA), Technology: MOSFET (Metal Oxide), FET Type: N-Channel, Current - Continuous Drain (Id) @ 25°C: 3.9A (Ta), Rds On (Max) @ Id, Vgs: 24mOhm @ 1.5A, 4.5V, Power Dissipation (Max): 370mW (Ta), Vgs(th) (Max) @ Id: 1V @ 394µA, Supplier Device Package: ULGA004-W-1010-RA01, Part Status: Obsolete, Drive Voltage (Max Rds On, Min Rds On): 1.5V, 4.5V, Vgs (Max): ±8V, Drain to Source Voltage (Vdss): 12 V, Gate Charge (Qg) (Max) @ Vgs: 7 nC @ 4.5 V, Input Capacitance (Ciss) (Max) @ Vds: 490 pF @ 10 V.
Інші пропозиції FK4B01120L1
Фото | Назва | Виробник | Інформація |
Доступність |
Ціна без ПДВ |
---|---|---|---|---|---|
![]() |
FK4B01120L1 | Виробник : Panasonic Electronic Components |
![]() Packaging: Tape & Reel (TR) Package / Case: 4-XFLGA, CSP Mounting Type: Surface Mount Operating Temperature: -40°C ~ 85°C (TA) Technology: MOSFET (Metal Oxide) FET Type: N-Channel Current - Continuous Drain (Id) @ 25°C: 3.9A (Ta) Rds On (Max) @ Id, Vgs: 24mOhm @ 1.5A, 4.5V Power Dissipation (Max): 370mW (Ta) Vgs(th) (Max) @ Id: 1V @ 394µA Supplier Device Package: ULGA004-W-1010-RA01 Part Status: Obsolete Drive Voltage (Max Rds On, Min Rds On): 1.5V, 4.5V Vgs (Max): ±8V Drain to Source Voltage (Vdss): 12 V Gate Charge (Qg) (Max) @ Vgs: 7 nC @ 4.5 V Input Capacitance (Ciss) (Max) @ Vds: 490 pF @ 10 V |
товар відсутній |
|
![]() |
FK4B01120L1 | Виробник : Panasonic Electronic Components |
![]() Packaging: Cut Tape (CT) Package / Case: 4-XFLGA, CSP Mounting Type: Surface Mount Operating Temperature: -40°C ~ 85°C (TA) Technology: MOSFET (Metal Oxide) FET Type: N-Channel Current - Continuous Drain (Id) @ 25°C: 3.9A (Ta) Rds On (Max) @ Id, Vgs: 24mOhm @ 1.5A, 4.5V Power Dissipation (Max): 370mW (Ta) Vgs(th) (Max) @ Id: 1V @ 394µA Supplier Device Package: ULGA004-W-1010-RA01 Part Status: Obsolete Drive Voltage (Max Rds On, Min Rds On): 1.5V, 4.5V Vgs (Max): ±8V Drain to Source Voltage (Vdss): 12 V Gate Charge (Qg) (Max) @ Vgs: 7 nC @ 4.5 V Input Capacitance (Ciss) (Max) @ Vds: 490 pF @ 10 V |
товар відсутній |
