B23JH NKK SWITCHES
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DPDT; ON-OFF-ON; 0.01A/28VAC; 0.01A/28VDC
Type of switch: toggle
Number of positions: 3
Contacts configuration: DPDT
Switching method: ON-OFF-ON
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Leads: for soldering
Operating temperature: -30...85°C
Knob height: 6.3mm
Max. contact resistance:: 50mΩ
Body dimensions: 13x9x9mm
Electrical life: 50000 cycles
Actuator material: brass
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mechanical durability: 100000 cycles
Mounting: THT
Body material: polyamide
Manufacturer series: B
Stable positions number: 3
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DPDT; ON-OFF-ON; 0.01A/28VAC; 0.01A/28VDC
Type of switch: toggle
Number of positions: 3
Contacts configuration: DPDT
Switching method: ON-OFF-ON
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Leads: for soldering
Operating temperature: -30...85°C
Knob height: 6.3mm
Max. contact resistance:: 50mΩ
Body dimensions: 13x9x9mm
Electrical life: 50000 cycles
Actuator material: brass
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mechanical durability: 100000 cycles
Mounting: THT
Body material: polyamide
Manufacturer series: B
Stable positions number: 3
на замовлення 32 шт:
термін постачання 21-30 дні (днів)
Кількість | Ціна без ПДВ |
---|---|
2+ | 376 грн |
3+ | 297.92 грн |
8+ | 281.68 грн |
Відгуки про товар
Написати відгук
Технічний опис B23JH NKK SWITCHES
Category: Toggle Switches, Description: Switch: toggle; Pos: 3; DPDT; ON-OFF-ON; 0.01A/28VAC; 0.01A/28VDC, Type of switch: toggle, Number of positions: 3, Contacts configuration: DPDT, Switching method: ON-OFF-ON, AC contacts rating @R: 0.01A / 28V AC, DC contacts rating @R: 0.01A / 28V DC, Leads: for soldering, Operating temperature: -30...85°C, Knob height: 6.3mm, Max. contact resistance:: 50mΩ, Body dimensions: 13x9x9mm, Electrical life: 50000 cycles, Actuator material: brass, Contact plating: gold-plated, Min. insulation resistance: 500MΩ, Mechanical durability: 100000 cycles, Mounting: THT, Body material: polyamide, Manufacturer series: B, Stable positions number: 3, кількість в упаковці: 1 шт.
Інші пропозиції B23JH за ціною від 338.01 грн до 516.09 грн
Фото | Назва | Виробник | Інформація |
Доступність |
Ціна без ПДВ | ||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
B23JH | Виробник : NKK SWITCHES |
Category: Toggle Switches Description: Switch: toggle; Pos: 3; DPDT; ON-OFF-ON; 0.01A/28VAC; 0.01A/28VDC Type of switch: toggle Number of positions: 3 Contacts configuration: DPDT Switching method: ON-OFF-ON AC contacts rating @R: 0.01A / 28V AC DC contacts rating @R: 0.01A / 28V DC Leads: for soldering Operating temperature: -30...85°C Knob height: 6.3mm Max. contact resistance:: 50mΩ Body dimensions: 13x9x9mm Electrical life: 50000 cycles Actuator material: brass Contact plating: gold-plated Min. insulation resistance: 500MΩ Mechanical durability: 100000 cycles Mounting: THT Body material: polyamide Manufacturer series: B Stable positions number: 3 кількість в упаковці: 1 шт |
на замовлення 32 шт: термін постачання 14-21 дні (днів) |
|
|||||||||||||||
B23JH | Виробник : NKK Switches |
Description: SWITCH TOGGLE DPDT 0.4VA 28V Packaging: Bulk Features: Epoxy Sealed Terminals Current Rating (Amps): 0.4VA (AC/DC) Mounting Type: Through Hole, Right Angle Circuit: DPDT Switch Function: On-Off-On Operating Temperature: -30°C ~ 85°C Termination Style: PC Pin Illumination: Non-Illuminated Bushing Thread: Unthreaded Actuator Length: 6.30mm Actuator Type: Standard Round Part Status: Active Voltage Rating - AC: 28 V Voltage Rating - DC: 28 V |
на замовлення 339 шт: термін постачання 21-31 дні (днів) |
|
|||||||||||||||
B23JH | Виробник : NKK Switches | Toggle Switches ON-OFF-ON DPDT |
на замовлення 55 шт: термін постачання 21-30 дні (днів) |
