AZ850P2-5 ZETTLER
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 1A; 0.5A/125VAC; PCB
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 5V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: bistable; subminiature
Mounting: PCB
Coil resistance: 125Ω
Coil voltage min.: 3.75V DC
Coil voltage max.: 10V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 2ms
Coil power consumption: 169mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Relay series: AZ850
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: two coils
Test voltage: 1.5kV
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 1A; 0.5A/125VAC; PCB
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 5V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: bistable; subminiature
Mounting: PCB
Coil resistance: 125Ω
Coil voltage min.: 3.75V DC
Coil voltage max.: 10V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 2ms
Coil power consumption: 169mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Relay series: AZ850
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: two coils
Test voltage: 1.5kV
на замовлення 796 шт:
термін постачання 21-30 дні (днів)
Кількість | Ціна без ПДВ |
---|---|
3+ | 159.84 грн |
5+ | 128.59 грн |
10+ | 89.64 грн |
25+ | 88.91 грн |
27+ | 84.5 грн |
Відгуки про товар
Написати відгук
Технічний опис AZ850P2-5 ZETTLER
Category: Miniature Electromagnetic Relays, Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 1A; 0.5A/125VAC; PCB, Type of relay: electromagnetic, Contacts configuration: DPDT, Rated coil voltage: 5V DC, Contact current max.: 1A, AC contacts rating @R: 0.5A / 125V AC, DC contacts rating @R: 1A / 30V DC, Switched voltage: max. 220V DC; max. 250V AC, Relay variant: bistable; subminiature, Mounting: PCB, Coil resistance: 125Ω, Coil voltage min.: 3.75V DC, Coil voltage max.: 10V DC, Operate time: 2ms, Body dimensions: 14x9x5mm, Release time: 2ms, Coil power consumption: 169mW, Mechanical durability: 100000000 cycles, Operating temperature: -55...90°C, Relay series: AZ850, Contact resistance: 70mΩ, Case: DIP10, Switching capacity: 30W; 50VA, Soldering temperature: 250°C, Terminal pitch: 2.54mm, Design: two coils, Test voltage: 1.5kV, кількість в упаковці: 1 шт.
Інші пропозиції AZ850P2-5 за ціною від 101.4 грн до 191.81 грн
Фото | Назва | Виробник | Інформація |
Доступність |
Ціна без ПДВ | ||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
AZ850P2-5 | Виробник : ZETTLER |
Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 1A; 0.5A/125VAC; PCB Type of relay: electromagnetic Contacts configuration: DPDT Rated coil voltage: 5V DC Contact current max.: 1A AC contacts rating @R: 0.5A / 125V AC DC contacts rating @R: 1A / 30V DC Switched voltage: max. 220V DC; max. 250V AC Relay variant: bistable; subminiature Mounting: PCB Coil resistance: 125Ω Coil voltage min.: 3.75V DC Coil voltage max.: 10V DC Operate time: 2ms Body dimensions: 14x9x5mm Release time: 2ms Coil power consumption: 169mW Mechanical durability: 100000000 cycles Operating temperature: -55...90°C Relay series: AZ850 Contact resistance: 70mΩ Case: DIP10 Switching capacity: 30W; 50VA Soldering temperature: 250°C Terminal pitch: 2.54mm Design: two coils Test voltage: 1.5kV кількість в упаковці: 1 шт |
на замовлення 796 шт: термін постачання 14-21 дні (днів) |
|
|||||||||||||
AZ850P2-5 | Виробник : Zettler Components Company | Signal Relay 5VDC 1A DPDT(14x9x5)mm THT |
на замовлення 882 шт: термін постачання 21-31 дні (днів) |
|
|||||||||||||
AZ850P2-5 Код товару: 33661 |
Реле |
товар відсутній
|
|||||||||||||||
AZ850P2-5 | Виробник : American Zettler |
Description: RELAY GENERAL PURPOSE DPDT 1A 5V Packaging: Box Mounting Type: Through Hole Coil Voltage: 5VDC Operating Temperature: -40°C ~ 70°C Termination Style: PC Pin Approval Agency: cUR, UL Relay Type: General Purpose Coil Current: 40 mA Coil Type: Latching, Dual Coil Seal Rating: Sealed - Fully Contact Material: Silver Palladium (AgPd), Gold (Au) Contact Form: DPDT (2 Form C) Contact Rating (Current): 1 A Switching Voltage: 250VAC, 220VDC - Max Must Release Voltage: 0.5 VDC Must Operate Voltage: 3.8 VDC Operate Time: 2 ms Release Time: 1 ms Part Status: Active Load - Max Switching: 250VA, 220W |
товар відсутній |
