AFG-3032GP GW INSTEK
![AFG-3021.pdf](/images/adobe-acrobat.png)
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 30MHz; colour,LCD TFT 4,3"; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 30MHz
Waveform frequency range: 1µHz...1MHz (ramp waveform); 1µHz...1MHz (triangle waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...30MHz (sinus waveform)
Kind of display used: colour; LCD TFT 4,3"
Number of channels: 2
Memory record length: 8Mpts
Vertical resolution: 16bit
Output parameters: impedance: 50Ω
Dimensions: 265x107x374mm
Interface: GPIB; LAN; USB
Kind of modulation: AM; FM; FSK; MSK; PSK; PWM; QAM; SUM
Waveforms: arbitrary; burst; cardiac; DC; ECG1; ECG2; ECG3; harmonic; ignition; impulse; ISO7637-2 TP2B; ISO7637-2 TP3A; ISO7637-2 TP3B; noise; rectangular; sinus; sweep; triangle
Sampling: 250Msps
Standard equipment: BNC cable
Measuring instrument features: 10 sets memory; insulated outputs; possibility to connect 4 units in series or 6 in parallel
Software: included
Manufacturer series: AFG-3000
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
товар відсутній
Відгуки про товар
Написати відгук
Технічний опис AFG-3032GP GW INSTEK
Category: Generators and Frequency Meters, Description: Generator: arbitrary, function; 30MHz; colour,LCD TFT 4,3"; Ch: 2, Type of generator: arbitrary, function, Maximum waveform frequency: 30MHz, Waveform frequency range: 1µHz...1MHz (ramp waveform); 1µHz...1MHz (triangle waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...30MHz (sinus waveform), Kind of display used: colour; LCD TFT 4,3", Number of channels: 2, Memory record length: 8Mpts, Vertical resolution: 16bit, Output parameters: impedance: 50Ω, Dimensions: 265x107x374mm, Interface: GPIB; LAN; USB, Kind of modulation: AM; FM; FSK; MSK; PSK; PWM; QAM; SUM, Waveforms: arbitrary; burst; cardiac; DC; ECG1; ECG2; ECG3; harmonic; ignition; impulse; ISO7637-2 TP2B; ISO7637-2 TP3A; ISO7637-2 TP3B; noise; rectangular; sinus; sweep; triangle, Sampling: 250Msps, Standard equipment: BNC cable, Measuring instrument features: 10 sets memory; insulated outputs; possibility to connect 4 units in series or 6 in parallel, Software: included, Manufacturer series: AFG-3000, Supply voltage: 100...240V AC, кількість в упаковці: 1 шт.
