50.12.9.048.1000 FINDER
Виробник: FINDERCategory: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 48VDC; Icontacts max: 15A
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 48V DC
Contact current max.: 15A
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 30V DC
Switched voltage: max. 220V DC; max. 400V AC
Relay variant: safety
Mounting: PCB
Relay series: 50.12
Operating temperature: -40...70°C
Body dimensions: 29x12.4x25mm
Coil resistance: 3.25kΩ
Coil current: 14.4mA
Contact material: AgNi
Coil power consumption: 700mW
Terminal pitch: 5mm
кількість в упаковці: 1 шт
товар відсутній
Відгуки про товар
Написати відгук
Технічний опис 50.12.9.048.1000 FINDER
Category: Miniature Electromagnetic Relays, Description: Relay: electromagnetic; DPDT; Ucoil: 48VDC; Icontacts max: 15A, Type of relay: electromagnetic, Contacts configuration: DPDT, Rated coil voltage: 48V DC, Contact current max.: 15A, AC contacts rating @R: 8A / 250V AC, DC contacts rating @R: 8A / 30V DC, Switched voltage: max. 220V DC; max. 400V AC, Relay variant: safety, Mounting: PCB, Relay series: 50.12, Operating temperature: -40...70°C, Body dimensions: 29x12.4x25mm, Coil resistance: 3.25kΩ, Coil current: 14.4mA, Contact material: AgNi, Coil power consumption: 700mW, Terminal pitch: 5mm, кількість в упаковці: 1 шт.
