Продукція > ZETTLER > Всі товари виробника ZETTLER (763) > Сторінка 4 з 13

Обрати Сторінку:   [  << Попередня Сторінка ]  1 2 3 4 5 6 7 8 9 10 11 12 13  [ Наступна Сторінка >> ]
Фото Назва Виробник Інформація Доступність
Ціна
без ПДВ
AZ832P2-2C-5DSE ZETTLER AZ832.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 3A; 2A/125VAC; 2A/30VDC
Mounting: PCB
Contact material: AgPd/Au 0,2μm
Contact current max.: 3A
Relay variant: bistable; miniature
DC contacts rating @R: 2A / 30V DC
Design: two coils
Coil power consumption: 96mW
AC contacts rating @R: 2A / 125V AC
Body dimensions: 20.2x10.2x10.6mm
Operating temperature: -40...85°C
Contacts configuration: DPDT
Switched voltage: max. 30V DC; max. 125V AC
Relay series: AZ832P
Rated coil voltage: 5V DC
Contact resistance: 50mΩ
Terminal pitch: 5.08mm
Type of relay: electromagnetic
Coil resistance: 167Ω
товар відсутній
AZ832P2-2C-12DE ZETTLER Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 3A; 2A/125VAC; 2A/30VDC
Body dimensions: 20.2x10.2x10.6mm
Operating temperature: -40...85°C
Relay series: AZ832P
Design: two coils
Contact resistance: 50mΩ
Contact current max.: 3A
Switched voltage: max. 30V DC; max. 125V AC
Coil power consumption: 128mW
Rated coil voltage: 12V DC
Contact material: AgPd/Au 0,2μm
AC contacts rating @R: 2A / 125V AC
DC contacts rating @R: 2A / 30V DC
Contacts configuration: DPDT
Coil resistance: 720Ω
Type of relay: electromagnetic
Terminal pitch: 5.08mm
Relay variant: bistable; miniature
Mounting: PCB
товар відсутній
AZ832P2-2C-12DSE ZETTLER Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 3A; 2A/125VAC; 2A/30VDC
Body dimensions: 20.2x10.2x10.6mm
Operating temperature: -40...85°C
Relay series: AZ832P
Design: two coils
Contact resistance: 50mΩ
Contact current max.: 3A
Switched voltage: max. 30V DC; max. 125V AC
Coil power consumption: 96mW
Rated coil voltage: 12V DC
Contact material: AgPd/Au 0,2μm
AC contacts rating @R: 2A / 125V AC
DC contacts rating @R: 2A / 30V DC
Contacts configuration: DPDT
Coil resistance: 960Ω
Type of relay: electromagnetic
Terminal pitch: 5.08mm
Relay variant: bistable; miniature
Mounting: PCB
товар відсутній
AZ832P2-2C-24DE ZETTLER AZ832P2-2C-24DE Miniature Electromagnetic Relays
товар відсутній
AZ832P2-2C-24DSE ZETTLER AZ832P2-2C-24DSE Miniature Electromagnetic Relays
товар відсутній
AZ832P2-2C-5DE ZETTLER AZ832P2-2C-5DE Miniature Electromagnetic Relays
товар відсутній
AZ832P2-2C-5DSE ZETTLER AZ832.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 3A; 2A/125VAC; 2A/30VDC
Mounting: PCB
Contact material: AgPd/Au 0,2μm
Contact current max.: 3A
Relay variant: bistable; miniature
DC contacts rating @R: 2A / 30V DC
Design: two coils
Coil power consumption: 96mW
AC contacts rating @R: 2A / 125V AC
Body dimensions: 20.2x10.2x10.6mm
Operating temperature: -40...85°C
Contacts configuration: DPDT
Switched voltage: max. 30V DC; max. 125V AC
Relay series: AZ832P
Rated coil voltage: 5V DC
Contact resistance: 50mΩ
Terminal pitch: 5.08mm
Type of relay: electromagnetic
Coil resistance: 167Ω
кількість в упаковці: 1000 шт
товар відсутній
AZ8462-12 ZETTLER Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; THT
Body dimensions: 15.2x7.7x9.2mm
Mounting: THT
Operating temperature: -40...105°C
Coil resistance: 1028Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 12V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
товар відсутній
AZ8462-24 ZETTLER Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; THT
Body dimensions: 15.2x7.7x9.2mm
Mounting: THT
Operating temperature: -40...105°C
Coil resistance: 4114Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 24V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
товар відсутній
AZ8462-12 ZETTLER Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; THT
Body dimensions: 15.2x7.7x9.2mm
Mounting: THT
Operating temperature: -40...105°C
Coil resistance: 1028Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 12V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8462-24 ZETTLER Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; THT
Body dimensions: 15.2x7.7x9.2mm
Mounting: THT
Operating temperature: -40...105°C
Coil resistance: 4114Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 24V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8462S-12 ZETTLER Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; SMT
Body dimensions: 15.2x7.7x9.2mm
Mounting: SMT
Operating temperature: -40...105°C
Coil resistance: 1028Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 12V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
товар відсутній
AZ8462S-24 ZETTLER az8462.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; SMT
Body dimensions: 15.2x7.7x9.2mm
Mounting: SMT
Operating temperature: -40...105°C
Coil resistance: 4114Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 24V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
товар відсутній
AZ8462S-3 ZETTLER Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 3VDC; 2A; 0.5A/125VAC; SMT
Body dimensions: 15.2x7.7x9.2mm
Mounting: SMT
Operating temperature: -40...105°C
Coil resistance: 64.3Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 3V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
товар відсутній
AZ8462S-5 ZETTLER Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 178Ω
Body dimensions: 15.2x7.7x9.2mm
Coil power consumption: 79mW
Operating temperature: -40...105°C
Relay series: AZ8462
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
товар відсутній
AZ8462S-12 ZETTLER Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; SMT
Body dimensions: 15.2x7.7x9.2mm
Mounting: SMT
Operating temperature: -40...105°C
Coil resistance: 1028Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 12V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8462S-24 ZETTLER az8462.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; SMT
Body dimensions: 15.2x7.7x9.2mm
Mounting: SMT
Operating temperature: -40...105°C
Coil resistance: 4114Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 24V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8462S-3 ZETTLER Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 3VDC; 2A; 0.5A/125VAC; SMT
Body dimensions: 15.2x7.7x9.2mm
Mounting: SMT
Operating temperature: -40...105°C
Coil resistance: 64.3Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 3V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8462S-5 ZETTLER Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 178Ω
Body dimensions: 15.2x7.7x9.2mm
Coil power consumption: 79mW
Operating temperature: -40...105°C
Relay series: AZ8462
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ850-12 AZ850-12 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 1A; 0.5A/125VAC; AZ850
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 12V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Relay series: AZ850
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: subminiature
Mounting: PCB
Coil resistance: 1028Ω
Coil voltage min.: 9V DC
Coil voltage max.: 30V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 1ms
Coil power consumption: 113mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: single coil
Test voltage: 1.5kV
на замовлення 8941 шт:
термін постачання 21-30 дні (днів)
5+78.68 грн
15+ 62.19 грн
39+ 58.45 грн
100+ 56.2 грн
Мінімальне замовлення: 5
AZ850-24 AZ850-24 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 1A; 0.5A/125VAC; AZ850
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Relay series: AZ850
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: subminiature
Mounting: PCB
Coil resistance: 2.88kΩ
Coil voltage min.: 18V DC
Coil voltage max.: 48V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 1ms
Coil power consumption: 113mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: single coil
Test voltage: 1.5kV
на замовлення 4296 шт:
термін постачання 21-30 дні (днів)
4+122.66 грн
5+ 98.16 грн
13+ 68.19 грн
36+ 64.44 грн
Мінімальне замовлення: 4
AZ850-5 AZ850-5 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 1A; 0.5A/125VAC; AZ850
Case: DIP10
Mounting: PCB
Operating temperature: -55...90°C
Design: single coil
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Soldering temperature: 250°C
Body dimensions: 14x9x5mm
Coil resistance: 178Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: subminiature
Relay series: AZ850
Rated coil voltage: 5V DC
Coil voltage min.: 3.75V DC
Coil voltage max.: 12.5V DC
Coil power consumption: 113mW
Operate time: 2ms
Release time: 1ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
на замовлення 3358 шт:
термін постачання 21-30 дні (днів)
4+114.59 грн
5+ 96.66 грн
13+ 70.43 грн
35+ 65.94 грн
500+ 65.19 грн
Мінімальне замовлення: 4
AZ850-12 AZ850-12 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 1A; 0.5A/125VAC; AZ850
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 12V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Relay series: AZ850
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: subminiature
Mounting: PCB
Coil resistance: 1028Ω
Coil voltage min.: 9V DC
Coil voltage max.: 30V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 1ms
Coil power consumption: 113mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: single coil
Test voltage: 1.5kV
кількість в упаковці: 1 шт
на замовлення 8941 шт:
термін постачання 14-21 дні (днів)
3+104.58 грн
5+ 98.04 грн
15+ 74.63 грн
39+ 70.14 грн
100+ 67.44 грн
Мінімальне замовлення: 3
AZ850-24 AZ850-24 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 1A; 0.5A/125VAC; AZ850
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Relay series: AZ850
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: subminiature
Mounting: PCB
Coil resistance: 2.88kΩ
Coil voltage min.: 18V DC
Coil voltage max.: 48V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 1ms
Coil power consumption: 113mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: single coil
Test voltage: 1.5kV
кількість в упаковці: 1 шт
на замовлення 4296 шт:
термін постачання 14-21 дні (днів)
2+147.19 грн
5+ 122.32 грн
13+ 81.82 грн
36+ 77.33 грн
Мінімальне замовлення: 2
AZ850-5 AZ850-5 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 1A; 0.5A/125VAC; AZ850
Case: DIP10
Mounting: PCB
Operating temperature: -55...90°C
Design: single coil
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Soldering temperature: 250°C
Body dimensions: 14x9x5mm
Coil resistance: 178Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: subminiature
Relay series: AZ850
Rated coil voltage: 5V DC
Coil voltage min.: 3.75V DC
Coil voltage max.: 12.5V DC
Coil power consumption: 113mW
Operate time: 2ms
Release time: 1ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
кількість в упаковці: 1 шт
на замовлення 3358 шт:
термін постачання 14-21 дні (днів)
3+137.5 грн
5+ 120.45 грн
13+ 84.52 грн
35+ 79.13 грн
500+ 78.23 грн
Мінімальне замовлення: 3
AZ850-5
+1
 		AZ850-5
Код товару: 91994 		ZETTLER paz850p005-datasheet.pdf Реле
Тип реле: Мініатюрне
Опис: Реле: електромагнітне; DPDT; Uобмотки: 5VDC; 0,5A / 125VAC; 1А
Габарити: 14x9x5 mm
Напруга котушки: 5 VDC
Струм макс.: 1 A
Конфігурація контактів: DPDT(2C)
Напруга перемикання: 125 VAC / 30 VDC
товар відсутній
1+60.5 грн
10+ 55.1 грн
AZ850P1-24 AZ850P1-24 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 1A; 0.5A/125VAC; AZ850
Operating temperature: -55...90°C
Body dimensions: 14x9x5mm
Soldering temperature: 250°C
Coil resistance: 3.84kΩ
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 24V DC
Coil voltage min.: 18V DC
Coil voltage max.: 57.6V DC
Coil power consumption: 84mW
Operate time: 2ms
Release time: 1ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: single coil
Mounting: PCB
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Case: DIP10
на замовлення 1085 шт:
термін постачання 21-30 дні (днів)
5+82.42 грн
12+ 74.18 грн
33+ 70.43 грн
500+ 67.44 грн
Мінімальне замовлення: 5
AZ850P1-3 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 3VDC; 1A; 0.5A/125VAC; AZ850
Operating temperature: -55...90°C
Body dimensions: 14x9x5mm
Soldering temperature: 250°C
Coil resistance: 90Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 3V DC
Coil voltage min.: 2.25V DC
Coil voltage max.: 8.7V DC
Coil power consumption: 84mW
Operate time: 2ms
Release time: 1ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: single coil
Mounting: PCB
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Case: DIP10
товар відсутній
AZ850P1-5 AZ850P1-5 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 1A; 0.5A/125VAC; AZ850
Operating temperature: -55...90°C
Body dimensions: 14x9x5mm
Soldering temperature: 250°C
Coil resistance: 250Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 5V DC
Coil voltage min.: 3.75V DC
Coil voltage max.: 14.5V DC
Coil power consumption: 84mW
Operate time: 2ms
Release time: 1ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: single coil
Mounting: PCB
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Case: DIP10
на замовлення 1191 шт:
термін постачання 21-30 дні (днів)
4+109.74 грн
5+ 88.42 грн
15+ 61.44 грн
40+ 58.45 грн
Мінімальне замовлення: 4
AZ850P1-24 AZ850P1-24 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 1A; 0.5A/125VAC; AZ850
Operating temperature: -55...90°C
Body dimensions: 14x9x5mm
Soldering temperature: 250°C
Coil resistance: 3.84kΩ
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 24V DC
Coil voltage min.: 18V DC
Coil voltage max.: 57.6V DC
Coil power consumption: 84mW
Operate time: 2ms
Release time: 1ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: single coil
Mounting: PCB
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Case: DIP10
кількість в упаковці: 1 шт
на замовлення 1085 шт:
термін постачання 14-21 дні (днів)
3+114.26 грн
5+ 102.71 грн
12+ 89.02 грн
33+ 84.52 грн
500+ 80.92 грн
Мінімальне замовлення: 3
AZ850P1-3 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 3VDC; 1A; 0.5A/125VAC; AZ850
Operating temperature: -55...90°C
Body dimensions: 14x9x5mm
Soldering temperature: 250°C
Coil resistance: 90Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 3V DC
Coil voltage min.: 2.25V DC
Coil voltage max.: 8.7V DC
Coil power consumption: 84mW
Operate time: 2ms
Release time: 1ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: single coil
Mounting: PCB
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Case: DIP10
кількість в упаковці: 1 шт
товар відсутній
AZ850P1-5 AZ850P1-5 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 1A; 0.5A/125VAC; AZ850
Operating temperature: -55...90°C
Body dimensions: 14x9x5mm
Soldering temperature: 250°C
Coil resistance: 250Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 5V DC
Coil voltage min.: 3.75V DC
Coil voltage max.: 14.5V DC
Coil power consumption: 84mW
Operate time: 2ms
Release time: 1ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: single coil
Mounting: PCB
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Case: DIP10
кількість в упаковці: 1 шт
на замовлення 1191 шт:
термін постачання 14-21 дні (днів)
3+131.69 грн
5+ 110.18 грн
15+ 73.73 грн
40+ 70.14 грн
Мінімальне замовлення: 3
AZ850P2-12 AZ850P2-12 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 1A; 0.5A/125VAC; AZ850
Case: DIP10
Soldering temperature: 250°C
Body dimensions: 14x9x5mm
Coil resistance: 720Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 12V DC
Coil voltage min.: 9V DC
Coil voltage max.: 24V DC
Coil power consumption: 169mW
Operate time: 2ms
Release time: 2ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: two coils
Mounting: PCB
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Operating temperature: -55...90°C
на замовлення 575 шт:
термін постачання 21-30 дні (днів)
3+176.72 грн
5+ 149.11 грн
9+ 106.4 грн
23+ 100.41 грн
Мінімальне замовлення: 3
AZ850P2-24 AZ850P2-24 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 1A; 0.5A/125VAC; AZ850
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Relay series: AZ850
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: bistable; subminiature
Mounting: PCB
Coil resistance: 1.92kΩ
Coil voltage min.: 18V DC
Coil voltage max.: 36V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 2ms
Coil power consumption: 169mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: two coils
Test voltage: 1.5kV
на замовлення 1531 шт:
термін постачання 21-30 дні (днів)
3+150.9 грн
5+ 126.63 грн
10+ 91.42 грн
27+ 86.17 грн
500+ 85.42 грн
Мінімальне замовлення: 3
AZ850P2-3 AZ850P2-3 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 3VDC; 1A; 0.5A/125VAC; AZ850
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 3V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Relay series: AZ850
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: bistable; subminiature
Mounting: PCB
Coil resistance: 45Ω
Coil voltage min.: 2.25V DC
Coil voltage max.: 6V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 2ms
Coil power consumption: 169mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: two coils
Test voltage: 1.5kV
на замовлення 992 шт:
термін постачання 21-30 дні (днів)
3+150.9 грн
5+ 128.13 грн
10+ 92.16 грн
26+ 87.67 грн
500+ 86.92 грн
Мінімальне замовлення: 3
AZ850P2-5 AZ850P2-5 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 1A; 0.5A/125VAC; AZ850
Operating temperature: -55...90°C
Body dimensions: 14x9x5mm
Mounting: PCB
Soldering temperature: 250°C
Coil resistance: 125Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 5V DC
Coil voltage min.: 3.75V DC
Coil voltage max.: 10V DC
Coil power consumption: 169mW
Operate time: 2ms
Release time: 2ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: two coils
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Case: DIP10
на замовлення 1604 шт:
термін постачання 21-30 дні (днів)
3+163 грн
5+ 131.13 грн
10+ 91.42 грн
27+ 86.17 грн
Мінімальне замовлення: 3
AZ850P2-12 AZ850P2-12 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 1A; 0.5A/125VAC; AZ850
Case: DIP10
Soldering temperature: 250°C
Body dimensions: 14x9x5mm
Coil resistance: 720Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 12V DC
Coil voltage min.: 9V DC
Coil voltage max.: 24V DC
Coil power consumption: 169mW
Operate time: 2ms
Release time: 2ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: two coils
Mounting: PCB
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Operating temperature: -55...90°C
кількість в упаковці: 1 шт
на замовлення 575 шт:
термін постачання 14-21 дні (днів)
2+212.06 грн
5+ 185.82 грн
9+ 127.68 грн
23+ 120.49 грн
Мінімальне замовлення: 2
AZ850P2-24 AZ850P2-24 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 1A; 0.5A/125VAC; AZ850
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Relay series: AZ850
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: bistable; subminiature
Mounting: PCB
Coil resistance: 1.92kΩ
Coil voltage min.: 18V DC
Coil voltage max.: 36V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 2ms
Coil power consumption: 169mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: two coils
Test voltage: 1.5kV
кількість в упаковці: 1 шт
на замовлення 1531 шт:
термін постачання 14-21 дні (днів)
2+181.08 грн
5+ 157.8 грн
10+ 109.7 грн
27+ 103.4 грн
500+ 102.5 грн
Мінімальне замовлення: 2
AZ850P2-3 AZ850P2-3 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 3VDC; 1A; 0.5A/125VAC; AZ850
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 3V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Relay series: AZ850
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: bistable; subminiature
Mounting: PCB
Coil resistance: 45Ω
Coil voltage min.: 2.25V DC
Coil voltage max.: 6V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 2ms
Coil power consumption: 169mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: two coils
Test voltage: 1.5kV
кількість в упаковці: 1 шт
на замовлення 992 шт:
термін постачання 14-21 дні (днів)
2+181.08 грн
5+ 159.67 грн
10+ 110.6 грн
26+ 105.2 грн
500+ 104.3 грн
Мінімальне замовлення: 2
AZ850P2-5 AZ850P2-5 ZETTLER az850.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 1A; 0.5A/125VAC; AZ850
Operating temperature: -55...90°C
Body dimensions: 14x9x5mm
Mounting: PCB
Soldering temperature: 250°C
Coil resistance: 125Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 5V DC
Coil voltage min.: 3.75V DC
Coil voltage max.: 10V DC
Coil power consumption: 169mW
Operate time: 2ms
Release time: 2ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: two coils
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Case: DIP10
кількість в упаковці: 1 шт
на замовлення 1604 шт:
термін постачання 14-21 дні (днів)
2+195.6 грн
5+ 163.41 грн
10+ 109.7 грн
27+ 103.4 грн
Мінімальне замовлення: 2
AZ851-12 ZETTLER AZ851.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 12V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 1028Ω
Body dimensions: 14.2x9.3x6.2mm
Coil power consumption: 170mW
Operating temperature: -40...85°C
Relay series: AZ851
Contact resistance: 50mΩ
Contact material: AgPd/Au 0,2μm
Terminal pitch: 2.54mm
товар відсутній
AZ851-24TR
+1
 		AZ851-24TR ZETTLER AZ851.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 2.88kΩ
Body dimensions: 14.2x9.3x6.2mm
Coil power consumption: 170mW
Operating temperature: -40...85°C
Relay series: AZ851
Contact resistance: 50mΩ
Contact material: AgPd/Au 0,2μm
Terminal pitch: 2.54mm
товар відсутній
AZ851-5 ZETTLER AZ851.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 178Ω
Body dimensions: 14.2x9.3x6.2mm
Coil power consumption: 170mW
Operating temperature: -40...85°C
Relay series: AZ851
Contact resistance: 50mΩ
Contact material: AgPd/Au 0,2μm
Terminal pitch: 2.54mm
товар відсутній
AZ851-12 ZETTLER AZ851.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 12V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 1028Ω
Body dimensions: 14.2x9.3x6.2mm
Coil power consumption: 170mW
Operating temperature: -40...85°C
Relay series: AZ851
Contact resistance: 50mΩ
Contact material: AgPd/Au 0,2μm
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ851-24TR
+1
 		AZ851-24TR ZETTLER AZ851.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 2.88kΩ
Body dimensions: 14.2x9.3x6.2mm
Coil power consumption: 170mW
Operating temperature: -40...85°C
Relay series: AZ851
Contact resistance: 50mΩ
Contact material: AgPd/Au 0,2μm
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ851-5 ZETTLER AZ851.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 178Ω
Body dimensions: 14.2x9.3x6.2mm
Coil power consumption: 170mW
Operating temperature: -40...85°C
Relay series: AZ851
Contact resistance: 50mΩ
Contact material: AgPd/Au 0,2μm
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8521-12 ZETTLER AZ8521.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 12V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 1028Ω
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
AZ8521-24 ZETTLER AZ8521.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 2.88kΩ
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 113mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
AZ8521-3 ZETTLER AZ8521.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 3VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 3V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 64.3Ω
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
AZ8521-4,5 ZETTLER AZ8521.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 4.5VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 4.5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 145Ω
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
AZ8521-5 ZETTLER AZ8521.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 178Ω
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
AZ8521-12 ZETTLER AZ8521.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 12V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 1028Ω
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8521-24 ZETTLER AZ8521.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 2.88kΩ
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 113mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8521-3 ZETTLER AZ8521.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 3VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 3V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 64.3Ω
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8521-4,5 ZETTLER AZ8521.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 4.5VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 4.5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 145Ω
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8521-5 ZETTLER AZ8521.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 178Ω
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8521S-12 ZETTLER AZ8521.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 12V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 1028Ω
Body dimensions: 10x6.5x5.65mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
AZ8521S-24 ZETTLER AZ8521.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 2.88kΩ
Body dimensions: 10x6.5x5.65mm
Coil power consumption: 113mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
AZ8521S-4,5 ZETTLER AZ8521.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 4.5VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 4.5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 145Ω
Body dimensions: 10x6.5x5.65mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
AZ8521S-5 ZETTLER AZ8521.pdf Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 178Ω
Body dimensions: 10x6.5x5.65mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
AZ832P2-2C-5DSE AZ832.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 3A; 2A/125VAC; 2A/30VDC
Mounting: PCB
Contact material: AgPd/Au 0,2μm
Contact current max.: 3A
Relay variant: bistable; miniature
DC contacts rating @R: 2A / 30V DC
Design: two coils
Coil power consumption: 96mW
AC contacts rating @R: 2A / 125V AC
Body dimensions: 20.2x10.2x10.6mm
Operating temperature: -40...85°C
Contacts configuration: DPDT
Switched voltage: max. 30V DC; max. 125V AC
Relay series: AZ832P
Rated coil voltage: 5V DC
Contact resistance: 50mΩ
Terminal pitch: 5.08mm
Type of relay: electromagnetic
Coil resistance: 167Ω
товар відсутній
AZ832P2-2C-12DE
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 3A; 2A/125VAC; 2A/30VDC
Body dimensions: 20.2x10.2x10.6mm
Operating temperature: -40...85°C
Relay series: AZ832P
Design: two coils
Contact resistance: 50mΩ
Contact current max.: 3A
Switched voltage: max. 30V DC; max. 125V AC
Coil power consumption: 128mW
Rated coil voltage: 12V DC
Contact material: AgPd/Au 0,2μm
AC contacts rating @R: 2A / 125V AC
DC contacts rating @R: 2A / 30V DC
Contacts configuration: DPDT
Coil resistance: 720Ω
Type of relay: electromagnetic
Terminal pitch: 5.08mm
Relay variant: bistable; miniature
Mounting: PCB
товар відсутній
AZ832P2-2C-12DSE
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 3A; 2A/125VAC; 2A/30VDC
Body dimensions: 20.2x10.2x10.6mm
Operating temperature: -40...85°C
Relay series: AZ832P
Design: two coils
Contact resistance: 50mΩ
Contact current max.: 3A
Switched voltage: max. 30V DC; max. 125V AC
Coil power consumption: 96mW
Rated coil voltage: 12V DC
Contact material: AgPd/Au 0,2μm
AC contacts rating @R: 2A / 125V AC
DC contacts rating @R: 2A / 30V DC
Contacts configuration: DPDT
Coil resistance: 960Ω
Type of relay: electromagnetic
Terminal pitch: 5.08mm
Relay variant: bistable; miniature
Mounting: PCB
товар відсутній
AZ832P2-2C-24DE
Виробник: ZETTLER
AZ832P2-2C-24DE Miniature Electromagnetic Relays
товар відсутній
AZ832P2-2C-24DSE
Виробник: ZETTLER
AZ832P2-2C-24DSE Miniature Electromagnetic Relays
товар відсутній
AZ832P2-2C-5DE
Виробник: ZETTLER
AZ832P2-2C-5DE Miniature Electromagnetic Relays
товар відсутній
AZ832P2-2C-5DSE AZ832.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 3A; 2A/125VAC; 2A/30VDC
Mounting: PCB
Contact material: AgPd/Au 0,2μm
Contact current max.: 3A
Relay variant: bistable; miniature
DC contacts rating @R: 2A / 30V DC
Design: two coils
Coil power consumption: 96mW
AC contacts rating @R: 2A / 125V AC
Body dimensions: 20.2x10.2x10.6mm
Operating temperature: -40...85°C
Contacts configuration: DPDT
Switched voltage: max. 30V DC; max. 125V AC
Relay series: AZ832P
Rated coil voltage: 5V DC
Contact resistance: 50mΩ
Terminal pitch: 5.08mm
Type of relay: electromagnetic
Coil resistance: 167Ω
кількість в упаковці: 1000 шт
товар відсутній
AZ8462-12
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; THT
Body dimensions: 15.2x7.7x9.2mm
Mounting: THT
Operating temperature: -40...105°C
Coil resistance: 1028Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 12V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
товар відсутній
AZ8462-24
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; THT
Body dimensions: 15.2x7.7x9.2mm
Mounting: THT
Operating temperature: -40...105°C
Coil resistance: 4114Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 24V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
товар відсутній
AZ8462-12
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; THT
Body dimensions: 15.2x7.7x9.2mm
Mounting: THT
Operating temperature: -40...105°C
Coil resistance: 1028Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 12V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8462-24
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; THT
Body dimensions: 15.2x7.7x9.2mm
Mounting: THT
Operating temperature: -40...105°C
Coil resistance: 4114Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 24V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8462S-12
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; SMT
Body dimensions: 15.2x7.7x9.2mm
Mounting: SMT
Operating temperature: -40...105°C
Coil resistance: 1028Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 12V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
товар відсутній
AZ8462S-24 az8462.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; SMT
Body dimensions: 15.2x7.7x9.2mm
Mounting: SMT
Operating temperature: -40...105°C
Coil resistance: 4114Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 24V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
товар відсутній
AZ8462S-3
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 3VDC; 2A; 0.5A/125VAC; SMT
Body dimensions: 15.2x7.7x9.2mm
Mounting: SMT
Operating temperature: -40...105°C
Coil resistance: 64.3Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 3V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
товар відсутній
AZ8462S-5
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 178Ω
Body dimensions: 15.2x7.7x9.2mm
Coil power consumption: 79mW
Operating temperature: -40...105°C
Relay series: AZ8462
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
товар відсутній
AZ8462S-12
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; SMT
Body dimensions: 15.2x7.7x9.2mm
Mounting: SMT
Operating temperature: -40...105°C
Coil resistance: 1028Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 12V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8462S-24 az8462.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; SMT
Body dimensions: 15.2x7.7x9.2mm
Mounting: SMT
Operating temperature: -40...105°C
Coil resistance: 4114Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 24V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8462S-3
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 3VDC; 2A; 0.5A/125VAC; SMT
Body dimensions: 15.2x7.7x9.2mm
Mounting: SMT
Operating temperature: -40...105°C
Coil resistance: 64.3Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Type of relay: electromagnetic
Relay variant: signal; subminiature
Relay series: AZ8462
Rated coil voltage: 3V DC
Coil power consumption: 79mW
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 2A
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8462S-5
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 178Ω
Body dimensions: 15.2x7.7x9.2mm
Coil power consumption: 79mW
Operating temperature: -40...105°C
Relay series: AZ8462
Contact resistance: 50mΩ
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ850-12 az850.pdf
AZ850-12
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 1A; 0.5A/125VAC; AZ850
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 12V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Relay series: AZ850
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: subminiature
Mounting: PCB
Coil resistance: 1028Ω
Coil voltage min.: 9V DC
Coil voltage max.: 30V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 1ms
Coil power consumption: 113mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: single coil
Test voltage: 1.5kV
на замовлення 8941 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна без ПДВ
5+78.68 грн
15+ 62.19 грн
39+ 58.45 грн
100+ 56.2 грн
Мінімальне замовлення: 5
AZ850-24 az850.pdf
AZ850-24
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 1A; 0.5A/125VAC; AZ850
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Relay series: AZ850
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: subminiature
Mounting: PCB
Coil resistance: 2.88kΩ
Coil voltage min.: 18V DC
Coil voltage max.: 48V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 1ms
Coil power consumption: 113mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: single coil
Test voltage: 1.5kV
на замовлення 4296 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна без ПДВ
4+122.66 грн
5+ 98.16 грн
13+ 68.19 грн
36+ 64.44 грн
Мінімальне замовлення: 4
AZ850-5 az850.pdf
AZ850-5
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 1A; 0.5A/125VAC; AZ850
Case: DIP10
Mounting: PCB
Operating temperature: -55...90°C
Design: single coil
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Soldering temperature: 250°C
Body dimensions: 14x9x5mm
Coil resistance: 178Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: subminiature
Relay series: AZ850
Rated coil voltage: 5V DC
Coil voltage min.: 3.75V DC
Coil voltage max.: 12.5V DC
Coil power consumption: 113mW
Operate time: 2ms
Release time: 1ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
на замовлення 3358 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна без ПДВ
4+114.59 грн
5+ 96.66 грн
13+ 70.43 грн
35+ 65.94 грн
500+ 65.19 грн
Мінімальне замовлення: 4
AZ850-12 az850.pdf
AZ850-12
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 1A; 0.5A/125VAC; AZ850
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 12V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Relay series: AZ850
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: subminiature
Mounting: PCB
Coil resistance: 1028Ω
Coil voltage min.: 9V DC
Coil voltage max.: 30V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 1ms
Coil power consumption: 113mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: single coil
Test voltage: 1.5kV
кількість в упаковці: 1 шт
на замовлення 8941 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
3+104.58 грн
5+ 98.04 грн
15+ 74.63 грн
39+ 70.14 грн
100+ 67.44 грн
Мінімальне замовлення: 3
AZ850-24 az850.pdf
AZ850-24
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 1A; 0.5A/125VAC; AZ850
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Relay series: AZ850
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: subminiature
Mounting: PCB
Coil resistance: 2.88kΩ
Coil voltage min.: 18V DC
Coil voltage max.: 48V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 1ms
Coil power consumption: 113mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: single coil
Test voltage: 1.5kV
кількість в упаковці: 1 шт
на замовлення 4296 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
2+147.19 грн
5+ 122.32 грн
13+ 81.82 грн
36+ 77.33 грн
Мінімальне замовлення: 2
AZ850-5 az850.pdf
AZ850-5
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 1A; 0.5A/125VAC; AZ850
Case: DIP10
Mounting: PCB
Operating temperature: -55...90°C
Design: single coil
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Soldering temperature: 250°C
Body dimensions: 14x9x5mm
Coil resistance: 178Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: subminiature
Relay series: AZ850
Rated coil voltage: 5V DC
Coil voltage min.: 3.75V DC
Coil voltage max.: 12.5V DC
Coil power consumption: 113mW
Operate time: 2ms
Release time: 1ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
кількість в упаковці: 1 шт
на замовлення 3358 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
3+137.5 грн
5+ 120.45 грн
13+ 84.52 грн
35+ 79.13 грн
500+ 78.23 грн
Мінімальне замовлення: 3
AZ850-5
Код товару: 91994		 paz850p005-datasheet.pdf
AZ850-5
+1
Виробник: ZETTLER
Реле
Тип реле: Мініатюрне
Опис: Реле: електромагнітне; DPDT; Uобмотки: 5VDC; 0,5A / 125VAC; 1А
Габарити: 14x9x5 mm
Напруга котушки: 5 VDC
Струм макс.: 1 A
Конфігурація контактів: DPDT(2C)
Напруга перемикання: 125 VAC / 30 VDC
товар відсутній
Кількість Ціна без ПДВ
1+60.5 грн
10+ 55.1 грн
AZ850P1-24 az850.pdf
AZ850P1-24
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 1A; 0.5A/125VAC; AZ850
Operating temperature: -55...90°C
Body dimensions: 14x9x5mm
Soldering temperature: 250°C
Coil resistance: 3.84kΩ
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 24V DC
Coil voltage min.: 18V DC
Coil voltage max.: 57.6V DC
Coil power consumption: 84mW
Operate time: 2ms
Release time: 1ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: single coil
Mounting: PCB
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Case: DIP10
на замовлення 1085 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна без ПДВ
5+82.42 грн
12+ 74.18 грн
33+ 70.43 грн
500+ 67.44 грн
Мінімальне замовлення: 5
AZ850P1-3 az850.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 3VDC; 1A; 0.5A/125VAC; AZ850
Operating temperature: -55...90°C
Body dimensions: 14x9x5mm
Soldering temperature: 250°C
Coil resistance: 90Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 3V DC
Coil voltage min.: 2.25V DC
Coil voltage max.: 8.7V DC
Coil power consumption: 84mW
Operate time: 2ms
Release time: 1ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: single coil
Mounting: PCB
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Case: DIP10
товар відсутній
AZ850P1-5 az850.pdf
AZ850P1-5
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 1A; 0.5A/125VAC; AZ850
Operating temperature: -55...90°C
Body dimensions: 14x9x5mm
Soldering temperature: 250°C
Coil resistance: 250Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 5V DC
Coil voltage min.: 3.75V DC
Coil voltage max.: 14.5V DC
Coil power consumption: 84mW
Operate time: 2ms
Release time: 1ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: single coil
Mounting: PCB
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Case: DIP10
на замовлення 1191 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна без ПДВ
4+109.74 грн
5+ 88.42 грн
15+ 61.44 грн
40+ 58.45 грн
Мінімальне замовлення: 4
AZ850P1-24 az850.pdf
AZ850P1-24
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 1A; 0.5A/125VAC; AZ850
Operating temperature: -55...90°C
Body dimensions: 14x9x5mm
Soldering temperature: 250°C
Coil resistance: 3.84kΩ
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 24V DC
Coil voltage min.: 18V DC
Coil voltage max.: 57.6V DC
Coil power consumption: 84mW
Operate time: 2ms
Release time: 1ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: single coil
Mounting: PCB
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Case: DIP10
кількість в упаковці: 1 шт
на замовлення 1085 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
3+114.26 грн
5+ 102.71 грн
12+ 89.02 грн
33+ 84.52 грн
500+ 80.92 грн
Мінімальне замовлення: 3
AZ850P1-3 az850.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 3VDC; 1A; 0.5A/125VAC; AZ850
Operating temperature: -55...90°C
Body dimensions: 14x9x5mm
Soldering temperature: 250°C
Coil resistance: 90Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 3V DC
Coil voltage min.: 2.25V DC
Coil voltage max.: 8.7V DC
Coil power consumption: 84mW
Operate time: 2ms
Release time: 1ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: single coil
Mounting: PCB
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Case: DIP10
кількість в упаковці: 1 шт
товар відсутній
AZ850P1-5 az850.pdf
AZ850P1-5
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 1A; 0.5A/125VAC; AZ850
Operating temperature: -55...90°C
Body dimensions: 14x9x5mm
Soldering temperature: 250°C
Coil resistance: 250Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 5V DC
Coil voltage min.: 3.75V DC
Coil voltage max.: 14.5V DC
Coil power consumption: 84mW
Operate time: 2ms
Release time: 1ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: single coil
Mounting: PCB
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Case: DIP10
кількість в упаковці: 1 шт
на замовлення 1191 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
3+131.69 грн
5+ 110.18 грн
15+ 73.73 грн
40+ 70.14 грн
Мінімальне замовлення: 3
AZ850P2-12 az850.pdf
AZ850P2-12
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 1A; 0.5A/125VAC; AZ850
Case: DIP10
Soldering temperature: 250°C
Body dimensions: 14x9x5mm
Coil resistance: 720Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 12V DC
Coil voltage min.: 9V DC
Coil voltage max.: 24V DC
Coil power consumption: 169mW
Operate time: 2ms
Release time: 2ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: two coils
Mounting: PCB
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Operating temperature: -55...90°C
на замовлення 575 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна без ПДВ
3+176.72 грн
5+ 149.11 грн
9+ 106.4 грн
23+ 100.41 грн
Мінімальне замовлення: 3
AZ850P2-24 az850.pdf
AZ850P2-24
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 1A; 0.5A/125VAC; AZ850
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Relay series: AZ850
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: bistable; subminiature
Mounting: PCB
Coil resistance: 1.92kΩ
Coil voltage min.: 18V DC
Coil voltage max.: 36V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 2ms
Coil power consumption: 169mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: two coils
Test voltage: 1.5kV
на замовлення 1531 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна без ПДВ
3+150.9 грн
5+ 126.63 грн
10+ 91.42 грн
27+ 86.17 грн
500+ 85.42 грн
Мінімальне замовлення: 3
AZ850P2-3 az850.pdf
AZ850P2-3
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 3VDC; 1A; 0.5A/125VAC; AZ850
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 3V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Relay series: AZ850
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: bistable; subminiature
Mounting: PCB
Coil resistance: 45Ω
Coil voltage min.: 2.25V DC
Coil voltage max.: 6V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 2ms
Coil power consumption: 169mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: two coils
Test voltage: 1.5kV
на замовлення 992 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна без ПДВ
3+150.9 грн
5+ 128.13 грн
10+ 92.16 грн
26+ 87.67 грн
500+ 86.92 грн
Мінімальне замовлення: 3
AZ850P2-5 az850.pdf
AZ850P2-5
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 1A; 0.5A/125VAC; AZ850
Operating temperature: -55...90°C
Body dimensions: 14x9x5mm
Mounting: PCB
Soldering temperature: 250°C
Coil resistance: 125Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 5V DC
Coil voltage min.: 3.75V DC
Coil voltage max.: 10V DC
Coil power consumption: 169mW
Operate time: 2ms
Release time: 2ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: two coils
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Case: DIP10
на замовлення 1604 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна без ПДВ
3+163 грн
5+ 131.13 грн
10+ 91.42 грн
27+ 86.17 грн
Мінімальне замовлення: 3
AZ850P2-12 az850.pdf
AZ850P2-12
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 1A; 0.5A/125VAC; AZ850
Case: DIP10
Soldering temperature: 250°C
Body dimensions: 14x9x5mm
Coil resistance: 720Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 12V DC
Coil voltage min.: 9V DC
Coil voltage max.: 24V DC
Coil power consumption: 169mW
Operate time: 2ms
Release time: 2ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: two coils
Mounting: PCB
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Operating temperature: -55...90°C
кількість в упаковці: 1 шт
на замовлення 575 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
2+212.06 грн
5+ 185.82 грн
9+ 127.68 грн
23+ 120.49 грн
Мінімальне замовлення: 2
AZ850P2-24 az850.pdf
AZ850P2-24
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 1A; 0.5A/125VAC; AZ850
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Relay series: AZ850
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: bistable; subminiature
Mounting: PCB
Coil resistance: 1.92kΩ
Coil voltage min.: 18V DC
Coil voltage max.: 36V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 2ms
Coil power consumption: 169mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: two coils
Test voltage: 1.5kV
кількість в упаковці: 1 шт
на замовлення 1531 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
2+181.08 грн
5+ 157.8 грн
10+ 109.7 грн
27+ 103.4 грн
500+ 102.5 грн
Мінімальне замовлення: 2
AZ850P2-3 az850.pdf
AZ850P2-3
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 3VDC; 1A; 0.5A/125VAC; AZ850
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 3V DC
Contact current max.: 1A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Relay series: AZ850
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: bistable; subminiature
Mounting: PCB
Coil resistance: 45Ω
Coil voltage min.: 2.25V DC
Coil voltage max.: 6V DC
Operate time: 2ms
Body dimensions: 14x9x5mm
Release time: 2ms
Coil power consumption: 169mW
Mechanical durability: 100000000 cycles
Operating temperature: -55...90°C
Contact resistance: 70mΩ
Case: DIP10
Switching capacity: 30W; 50VA
Soldering temperature: 250°C
Terminal pitch: 2.54mm
Design: two coils
Test voltage: 1.5kV
кількість в упаковці: 1 шт
на замовлення 992 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
2+181.08 грн
5+ 159.67 грн
10+ 110.6 грн
26+ 105.2 грн
500+ 104.3 грн
Мінімальне замовлення: 2
AZ850P2-5 az850.pdf
AZ850P2-5
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 1A; 0.5A/125VAC; AZ850
Operating temperature: -55...90°C
Body dimensions: 14x9x5mm
Mounting: PCB
Soldering temperature: 250°C
Coil resistance: 125Ω
Contacts configuration: DPDT
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Type of relay: electromagnetic
Relay variant: bistable; subminiature
Relay series: AZ850
Rated coil voltage: 5V DC
Coil voltage min.: 3.75V DC
Coil voltage max.: 10V DC
Coil power consumption: 169mW
Operate time: 2ms
Release time: 2ms
Switched voltage: max. 220V DC; max. 250V AC
Contact current max.: 1A
Switching capacity: 30W; 50VA
Contact resistance: 70mΩ
Design: two coils
Mechanical durability: 100000000 cycles
Test voltage: 1.5kV
Terminal pitch: 2.54mm
Case: DIP10
кількість в упаковці: 1 шт
на замовлення 1604 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
2+195.6 грн
5+ 163.41 грн
10+ 109.7 грн
27+ 103.4 грн
Мінімальне замовлення: 2
AZ851-12 AZ851.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 12V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 1028Ω
Body dimensions: 14.2x9.3x6.2mm
Coil power consumption: 170mW
Operating temperature: -40...85°C
Relay series: AZ851
Contact resistance: 50mΩ
Contact material: AgPd/Au 0,2μm
Terminal pitch: 2.54mm
товар відсутній
AZ851-24TR AZ851.pdf
AZ851-24TR
+1
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 2.88kΩ
Body dimensions: 14.2x9.3x6.2mm
Coil power consumption: 170mW
Operating temperature: -40...85°C
Relay series: AZ851
Contact resistance: 50mΩ
Contact material: AgPd/Au 0,2μm
Terminal pitch: 2.54mm
товар відсутній
AZ851-5 AZ851.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 178Ω
Body dimensions: 14.2x9.3x6.2mm
Coil power consumption: 170mW
Operating temperature: -40...85°C
Relay series: AZ851
Contact resistance: 50mΩ
Contact material: AgPd/Au 0,2μm
Terminal pitch: 2.54mm
товар відсутній
AZ851-12 AZ851.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 12V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 1028Ω
Body dimensions: 14.2x9.3x6.2mm
Coil power consumption: 170mW
Operating temperature: -40...85°C
Relay series: AZ851
Contact resistance: 50mΩ
Contact material: AgPd/Au 0,2μm
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ851-24TR AZ851.pdf
AZ851-24TR
+1
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 2.88kΩ
Body dimensions: 14.2x9.3x6.2mm
Coil power consumption: 170mW
Operating temperature: -40...85°C
Relay series: AZ851
Contact resistance: 50mΩ
Contact material: AgPd/Au 0,2μm
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ851-5 AZ851.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 1A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 178Ω
Body dimensions: 14.2x9.3x6.2mm
Coil power consumption: 170mW
Operating temperature: -40...85°C
Relay series: AZ851
Contact resistance: 50mΩ
Contact material: AgPd/Au 0,2μm
Terminal pitch: 2.54mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8521-12 AZ8521.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 12V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 1028Ω
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
AZ8521-24 AZ8521.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 2.88kΩ
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 113mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
AZ8521-3 AZ8521.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 3VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 3V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 64.3Ω
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
AZ8521-4,5 AZ8521.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 4.5VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 4.5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 145Ω
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
AZ8521-5 AZ8521.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 178Ω
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
AZ8521-12 AZ8521.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 12V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 1028Ω
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8521-24 AZ8521.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 2.88kΩ
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 113mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8521-3 AZ8521.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 3VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 3V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 64.3Ω
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8521-4,5 AZ8521.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 4.5VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 4.5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 145Ω
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8521-5 AZ8521.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 2A; 0.5A/125VAC; THT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: THT
Coil resistance: 178Ω
Body dimensions: 10x6.5x5.4mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
кількість в упаковці: 1000 шт
товар відсутній
AZ8521S-12 AZ8521.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 12V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 1028Ω
Body dimensions: 10x6.5x5.65mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
AZ8521S-24 AZ8521.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 2.88kΩ
Body dimensions: 10x6.5x5.65mm
Coil power consumption: 113mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
AZ8521S-4,5 AZ8521.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 4.5VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 4.5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 145Ω
Body dimensions: 10x6.5x5.65mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
AZ8521S-5 AZ8521.pdf
Виробник: ZETTLER
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 5VDC; 2A; 0.5A/125VAC; SMT
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 5V DC
Contact current max.: 2A
AC contacts rating @R: 0.5A / 125V AC
DC contacts rating @R: 2A / 30V DC
Switched voltage: max. 220V DC; max. 250V AC
Relay variant: signal; subminiature
Mounting: SMT
Coil resistance: 178Ω
Body dimensions: 10x6.5x5.65mm
Coil power consumption: 79mW
Operating temperature: -40...85°C
Relay series: AZ8521
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 2.2mm
товар відсутній
Обрати Сторінку:   [  << Попередня Сторінка ]  1 2 3 4 5 6 7 8 9 10 11 12 13  [ Наступна Сторінка >> ]
