Продукція > NKK SWITCHES > Всі товари виробника NKK SWITCHES (43644) > Сторінка 628 з 728

Обрати Сторінку:   [  << Попередня Сторінка ]  1 72 144 216 288 360 432 504 576 623 624 625 626 627 628 629 630 631 632 633 648 720 728  [ Наступна Сторінка >> ]
Фото Назва Виробник Інформація Доступність
Ціна
без ПДВ
G15AH NKK SWITCHES G12AV.pdf Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPDT; ON-(ON); 0.1A/28VAC; 0.1A/28VDC; THT
Mounting: THT
Operating temperature: -25...85°C
Manufacturer series: G
AC contacts rating @R: 0.1A / 28V AC
Lever length: 3.8mm
Contacts configuration: SPDT
Stable positions number: 1
Number of terminals: 5
Leads: angled; for soldering
Operating Force: 0.93N
Body material: polyamide
Body dimensions: 7x7.6x4.9mm
Kind of toggle: round
Switching method: ON-(ON)
Min. insulation resistance: 500MΩ
Kind of material: fiber glass reinforced
Max. contact resistance:: 80mΩ
Electrical life: 50000 cycles
Illumination: none
Number of positions: 2
Actuator material: polyamide
Contact plating: gold-plated
Terminal pitch: 2.54mm
Contact material: phosphor bronze
Poles number: 1
Type of switch: toggle
Mechanical durability: 50000 cycles
DC contacts rating @R: 0.1A / 28V DC
кількість в упаковці: 1 шт
товар відсутній
G18AH NKK SWITCHES G12AV.pdf Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; (ON)-OFF-(ON); 0.1A/28VAC; 0.1A/28VDC
Type of switch: toggle
Contacts configuration: SP3T
Illumination: none
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: (ON)-OFF-(ON)
Mechanical durability: 50000 cycles
Mounting: THT
Number of positions: 3
Operating temperature: -25...85°C
Leads: angled; for soldering
Electrical life: 50000 cycles
Lever length: 3.8mm
Manufacturer series: G
Stable positions number: 1
Body material: polyamide
Poles number: 1
Contact material: phosphor bronze
Actuator material: polyamide
Operating Force: 0.93N
Kind of toggle: round
Kind of material: fiber glass reinforced
Contact plating: gold-plated
Max. contact resistance:: 80mΩ
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Body dimensions: 7x7.6x4.9mm
Number of terminals: 5
кількість в упаковці: 1 шт
товар відсутній
G18AP NKK SWITCHES Gtoggles.pdf G18AP Toggle Switches
товар відсутній
G18AV NKK SWITCHES Gtoggles.pdf G18AV Toggle Switches
товар відсутній
G18KP NKK SWITCHES G12KP.pdf Category: Rocker Switches
Description: ROCKER; SP3T; Pos: 3; (ON)-OFF-(ON); 0.1A/28VAC; 0.1A/28VDC; none
Operating temperature: -25...85°C
Body material: polyamide
Manufacturer series: G
Mounting: THT
Operating Force: 0.81N
Body dimensions: 4.5x7x7mm
Switching method: (ON)-OFF-(ON)
Min. insulation resistance: 500MΩ
Kind of material: fiber glass reinforced
Max. contact resistance:: 80mΩ
Electrical life: 50000 cycles
Illumination: none
Number of positions: 3
Contact plating: gold-plated
Terminal pitch: 2.54mm
Contact material: phosphor bronze
Poles number: 1
Type of switch: ROCKER
Mechanical durability: 50000 cycles
DC contacts rating @R: 0.1A / 28V DC
Body colour: black
AC contacts rating @R: 0.1A / 28V AC
Contacts configuration: SP3T
Stable positions number: 1
Number of terminals: 5
Leads: for soldering; straight
кількість в упаковці: 1 шт
товар відсутній
G19AH NKK SWITCHES Gtoggles.pdf G19AH Toggle Switches
товар відсутній
G22AH NKK SWITCHES G12AV.pdf Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-ON; 0.1A/28VAC; 0.1A/28VDC; THT
Type of switch: toggle
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-ON
Number of terminals: 6
Mounting: THT
Leads: angled; for soldering
Operating temperature: -25...85°C
Body dimensions: 7x7.6x4.9mm
Min. insulation resistance: 500MΩ
Max. contact resistance:: 80mΩ
Manufacturer series: G
Electrical life: 100000 cycles
Contact plating: gold-plated
Terminal pitch: 2.54mm
Contact material: phosphor bronze
Mechanical durability: 100000 cycles
Illumination: none
Operating Force: 1.2N
Body material: polyamide
Actuator material: polyamide
Poles number: 2
Kind of material: fiber glass reinforced
Stable positions number: 2
Kind of toggle: round
Lever length: 3.8mm
кількість в упаковці: 1 шт
товар відсутній
G22AP G22AP NKK SWITCHES Gtoggles.pdf Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-ON; 0.1A/28VAC; 0.1A/28VDC; THT
Type of switch: toggle
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-ON
Illumination: none
Leads: for soldering; straight
Operating temperature: -25...85°C
Electrical life: 100000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 1.2N
Mechanical durability: 100000 cycles
Body material: polyamide
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Mounting: THT
Body dimensions: 4.5x7x7mm
Number of terminals: 6
Manufacturer series: G
Stable positions number: 2
Poles number: 2
Kind of material: fiber glass reinforced
Lever length: 3.8mm
Kind of toggle: round
Actuator material: polyamide
на замовлення 92 шт:
термін постачання 14-21 дні (днів)
1+412.8 грн
4+ 312.99 грн
9+ 284.95 грн
G22AV NKK SWITCHES Gtoggles.pdf Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-ON; 0.1A/28VAC; 0.1A/28VDC; THT
Type of switch: toggle
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-ON
Illumination: none
Leads: angled; for soldering
Operating temperature: -25...85°C
Electrical life: 100000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 1.2N
Mechanical durability: 100000 cycles
Body material: polyamide
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Mounting: THT
Body dimensions: 5.3x7.6x7.4mm
Number of terminals: 6
Manufacturer series: G
Stable positions number: 2
Poles number: 2
Kind of material: fiber glass reinforced
Lever length: 3.8mm
Kind of toggle: round
Actuator material: polyamide
товар відсутній
G22KP NKK SWITCHES GRocker-1.pdf Category: Rocker Switches
Description: ROCKER; DPDT; Pos: 2; ON-ON; 0.1A/28VAC; 0.1A/28VDC; none; -25÷85°C
Type of switch: ROCKER
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-ON
Illumination: none
Leads: for soldering; straight
Operating temperature: -25...85°C
Electrical life: 100000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 1.06N
Mechanical durability: 100000 cycles
Body colour: black
Body material: polyamide
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Mounting: THT
Body dimensions: 4.5x7x7mm
Number of terminals: 6
Manufacturer series: G
Stable positions number: 2
Poles number: 2
Kind of material: fiber glass reinforced
товар відсутній
G23AH NKK SWITCHES G12AV.pdf Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DP3T; ON-OFF-ON; 0.1A/28VAC; 0.1A/28VDC
Type of switch: toggle
Number of positions: 3
Contacts configuration: DP3T
Switching method: ON-OFF-ON
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Leads: angled; for soldering
Number of terminals: 6
Terminal pitch: 2.54mm
Operating temperature: -25...85°C
Kind of toggle: round
Max. contact resistance:: 80mΩ
Body dimensions: 7x7.6x4.9mm
Electrical life: 100000 cycles
Actuator material: polyamide
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mechanical durability: 100000 cycles
Contact material: phosphor bronze
Mounting: THT
Body material: polyamide
Illumination: none
Operating Force: 1.2N
Poles number: 2
Lever length: 3.8mm
Manufacturer series: G
Kind of material: fiber glass reinforced
Stable positions number: 3
кількість в упаковці: 1 шт
товар відсутній
G23AP G23AP NKK SWITCHES Gtoggles.pdf Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DP3T; ON-OFF-ON; 0.1A/28VAC; 0.1A/28VDC
Type of switch: toggle
Number of positions: 3
Contacts configuration: DP3T
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-OFF-ON
Illumination: none
Leads: for soldering; straight
Operating temperature: -25...85°C
Electrical life: 100000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 1.2N
Mechanical durability: 100000 cycles
Body material: polyamide
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Mounting: THT
Body dimensions: 4.5x7x7mm
Number of terminals: 6
Manufacturer series: G
Stable positions number: 3
Poles number: 2
Kind of material: fiber glass reinforced
Lever length: 3.8mm
Kind of toggle: round
Actuator material: polyamide
товар відсутній
G23AV NKK SWITCHES Gtoggles.pdf Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DP3T; ON-OFF-ON; 0.1A/28VAC; 0.1A/28VDC
Type of switch: toggle
Number of positions: 3
Contacts configuration: DP3T
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-OFF-ON
Illumination: none
Leads: angled; for soldering
Operating temperature: -25...85°C
Electrical life: 100000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 1.2N
Mechanical durability: 100000 cycles
Body material: polyamide
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Mounting: THT
Body dimensions: 5.3x7.6x7.4mm
Number of terminals: 6
Manufacturer series: G
Stable positions number: 3
Poles number: 2
Kind of material: fiber glass reinforced
Lever length: 3.8mm
Kind of toggle: round
Actuator material: polyamide
товар відсутній
G23KP NKK SWITCHES GRocker-1.pdf Category: Rocker Switches
Description: ROCKER; DP3T; Pos: 3; ON-OFF-ON; 0.1A/28VAC; 0.1A/28VDC; none; THT
Type of switch: ROCKER
Number of positions: 3
Contacts configuration: DP3T
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-OFF-ON
Illumination: none
Leads: for soldering; straight
Operating temperature: -25...85°C
Electrical life: 100000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 1.06N
Mechanical durability: 100000 cycles
Body colour: black
Body material: polyamide
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Mounting: THT
Body dimensions: 4.5x7x7mm
Number of terminals: 6
Manufacturer series: G
Stable positions number: 3
Poles number: 2
Kind of material: fiber glass reinforced
товар відсутній
G29AH NKK SWITCHES Gtoggles.pdf G29AH Toggle Switches
товар відсутній
G29AP NKK SWITCHES Gtoggles.pdf G29AP Toggle Switches
товар відсутній
G3B15AB NKK SWITCHES G3B15AB.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-(ON)
Illumination: none
Leads: Gull Wing
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 2N
Mechanical durability: 50000 cycles
Button shape: round
Body material: PPS
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mounting: SMD
Body dimensions: 5x11x9mm
Number of terminals: 3
Manufacturer series: G3B
Stable positions number: 1
Key stroke: 1.1mm
Poles number: 1
кількість в упаковці: 1 шт
товар відсутній
G3B15AB-S NKK SWITCHES G3B15AB.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-(ON)
Illumination: none
Leads: Gull Wing
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 2N
Mechanical durability: 50000 cycles
Button shape: round
Body material: PPS
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mounting: SMD
Body dimensions: 5x11x9mm
Number of terminals: 3
Manufacturer series: G3B
Stable positions number: 1
Key stroke: 1.1mm
Poles number: 1
кількість в упаковці: 1 шт
товар відсутній
G3B15AH G3B15AH NKK SWITCHES G3Bseries.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for PCB; right
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 9x8.5x5mm
Manufacturer series: G3B
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 116 шт:
термін постачання 14-21 дні (днів)
1+492.48 грн
3+ 418.74 грн
8+ 381.24 грн
G3B15AH-R
+1
 		G3B15AH-R NKK SWITCHES G3B15AB.pdf G3Bseries.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for PCB; right
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 9x8.5x5mm
Manufacturer series: G3B
Kind of package: reel
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 500 шт:
термін постачання 14-21 дні (днів)
1+519.36 грн
3+ 418.74 грн
8+ 381.24 грн
100+ 377.07 грн
G3B15AP G3B15AP NKK SWITCHES G3Bseries.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for PCB
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 9x8.5x5mm
Manufacturer series: G3B
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 132 шт:
термін постачання 14-21 дні (днів)
1+497.28 грн
3+ 379.7 грн
8+ 345.69 грн
G3B25AB-S NKK SWITCHES G3B15AB.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-(ON)
Illumination: none
Leads: Gull Wing
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 2N
Mechanical durability: 50000 cycles
Button shape: round
Body material: PPS
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mounting: SMD
Body dimensions: 5x11x9mm
Number of terminals: 6
Manufacturer series: G3B
Stable positions number: 1
Key stroke: 1.1mm
Poles number: 2
кількість в упаковці: 1 шт
товар відсутній
G3B25AH NKK SWITCHES G3B15AB.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-(ON)
Illumination: none
Leads: Gull Wing
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 2N
Mechanical durability: 50000 cycles
Button shape: round
Body material: PPS
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mounting: SMD
Body dimensions: 8.5x9x5.55mm
Number of terminals: 6
Manufacturer series: G3B
Stable positions number: 1
Key stroke: 1.1mm
Poles number: 2
кількість в упаковці: 1 шт
товар відсутній
G3B25AP NKK SWITCHES G3B25AP.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-(ON)
Illumination: none
Leads: Gull Wing
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 2N
Mechanical durability: 50000 cycles
Button shape: round
Body material: PPS
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mounting: SMD
Body dimensions: 5x11x9mm
Number of terminals: 6
Manufacturer series: G3B
Stable positions number: 1
Key stroke: 1.1mm
Poles number: 2
кількість в упаковці: 1 шт
товар відсутній
G3B25AP-S NKK SWITCHES G3B25AP.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-(ON)
Illumination: none
Leads: Gull Wing
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 2N
Mechanical durability: 50000 cycles
Button shape: round
Body material: PPS
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mounting: SMD
Body dimensions: 5x11x9mm
Number of terminals: 6
Manufacturer series: G3B
Stable positions number: 1
Key stroke: 1.1mm
Poles number: 2
кількість в упаковці: 1 шт
товар відсутній
G3T12AB-S NKK SWITCHES G3T12AB-S.pdf Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPDT; ON-ON; 0.1A/28VAC; 0.1A/28VDC; SMD
Mounting: SMD
Operating temperature: -30...85°C
Manufacturer series: G3T
Lever length: 3.8mm
Contacts configuration: SPDT
Stable positions number: 2
Number of terminals: 5
Leads: Gull Wing
Operating Force: 1.7N
Body material: PPS
Body dimensions: 5x11x9mm
Kind of toggle: round
Switching method: ON-ON
Min. insulation resistance: 500MΩ
Max. contact resistance:: 80mΩ
Electrical life: 50000 cycles
Illumination: none
Number of positions: 2
Contact plating: gold-plated
Terminal pitch: 2.54mm
Contact material: phosphor bronze
Poles number: 1
Type of switch: toggle
Mechanical durability: 50000 cycles
DC contacts rating @R: 0.1A / 28V DC
AC contacts rating @R: 0.1A / 28V AC
кількість в упаковці: 1 шт
товар відсутній
G3T12AH G3T12AH NKK SWITCHES G3Tseries.pdf Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPDT; ON-ON; 0.01A/28VAC; 0.01A/28VDC; G3T
Operating temperature: -30...85°C
Manufacturer series: G3T
Type of switch: toggle
Contacts configuration: SPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-ON
Stable positions number: 2
Knob height: 3.8mm
Number of positions: 2
Mechanical durability: 50000 cycles
Max. contact resistance:: 80mΩ
Min. insulation resistance: 500MΩ
Body dimensions: 8.5x9x5mm
Leads: for PCB
Electrical life: 50000 cycles
кількість в упаковці: 1 шт
на замовлення 42 шт:
термін постачання 14-21 дні (днів)
1+355.2 грн
4+ 313.08 грн
10+ 285.03 грн
100+ 283.47 грн
G3T12AH-R NKK SWITCHES G3T12AB-S.pdf G3Tseries.pdf Category: Standard Switches
Description: Switch: toggle; Pos: 2; SPDT; 0.01A/28VAC; 0.01A/28VDC; ON-ON; 500MΩ
Operating temperature: -30...85°C
Manufacturer series: G3T
Type of switch: toggle
Contacts configuration: SPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-ON
Stable positions number: 2
Knob height: 3.8mm
Number of positions: 2
Mechanical durability: 50000 cycles
Max. contact resistance:: 80mΩ
Min. insulation resistance: 500MΩ
Body dimensions: 8.5x9x5mm
Leads: for PCB
Electrical life: 50000 cycles
кількість в упаковці: 1 шт
товар відсутній
G3T12AP
+1
 		G3T12AP NKK SWITCHES G3T12AB-S.pdf Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPDT; ON-ON; 0.1A/28VAC; 0.1A/28VDC; 8.5x5mm
Operating temperature: -30...85°C
Contacts configuration: SPDT
Stable positions number: 2
Leads: for soldering
Kind of toggle: round
Switching method: ON-ON
Electrical life: 50000 cycles
Number of positions: 2
Mounting hole diameter: 8.5x5mm
Type of switch: toggle
DC contacts rating @R: 0.1A / 28V DC
AC contacts rating @R: 0.1A / 28V AC
кількість в упаковці: 1 шт
на замовлення 170 шт:
термін постачання 14-21 дні (днів)
1+398.4 грн
4+ 269.79 грн
11+ 245.62 грн
G3T13AB NKK SWITCHES G3T12AB-S.pdf Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; ON-OFF-ON; 0.1A/28VAC; 0.1A/28VDC
Type of switch: toggle
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Contacts configuration: SP3T
Max. contact resistance:: 80mΩ
Switching method: ON-OFF-ON
Number of positions: 3
Stable positions number: 3
Leads: Gull Wing
Body dimensions: 5x11x9mm
Mechanical durability: 50000 cycles
Operating temperature: -30...85°C
Operating Force: 1.7N
Lever length: 3.8mm
Electrical life: 50000 cycles
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Contact material: phosphor bronze
Body material: PPS
Mounting: SMD
Illumination: none
Manufacturer series: G3T
Number of terminals: 5
Poles number: 1
Kind of toggle: round
кількість в упаковці: 1 шт
товар відсутній
G3T13AH NKK SWITCHES G3T12AB-S.pdf Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; ON-OFF-ON; 0.1A/28VAC; 0.1A/28VDC
Type of switch: toggle
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Contacts configuration: SP3T
Max. contact resistance:: 80mΩ
Switching method: ON-OFF-ON
Number of positions: 3
Stable positions number: 3
Leads: Gull Wing
Body dimensions: 8.5x9x5.55mm
Mechanical durability: 50000 cycles
Operating temperature: -30...85°C
Operating Force: 1.7N
Lever length: 3.8mm
Electrical life: 50000 cycles
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Contact material: phosphor bronze
Body material: PPS
Mounting: SMD
Illumination: none
Manufacturer series: G3T
Number of terminals: 5
Poles number: 1
Kind of toggle: round
кількість в упаковці: 1 шт
товар відсутній
G3T13AP NKK SWITCHES G3T12AB-S.pdf Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; ON-OFF-ON; 0.1A/28VAC; 0.1A/28VDC
Type of switch: toggle
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Contacts configuration: SP3T
Max. contact resistance:: 80mΩ
Switching method: ON-OFF-ON
Number of positions: 3
Stable positions number: 3
Leads: Gull Wing
Body dimensions: 5x8.5x9mm
Mechanical durability: 50000 cycles
Operating temperature: -30...85°C
Operating Force: 1.7N
Lever length: 3.8mm
Electrical life: 50000 cycles
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Contact material: phosphor bronze
Body material: PPS
Mounting: SMD
Illumination: none
Manufacturer series: G3T
Number of terminals: 5
Poles number: 1
Kind of toggle: round
кількість в упаковці: 1 шт
товар відсутній
G3T18AH NKK SWITCHES G3T12AB-S.pdf Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; (ON)-OFF-(ON); 0.1A/28VAC; 0.1A/28VDC
Type of switch: toggle
Contacts configuration: SP3T
Illumination: none
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: (ON)-OFF-(ON)
Mechanical durability: 50000 cycles
Mounting: SMD
Number of positions: 3
Operating temperature: -30...85°C
Leads: Gull Wing
Electrical life: 50000 cycles
Lever length: 3.8mm
Manufacturer series: G3T
Stable positions number: 1
Body material: PPS
Poles number: 1
Contact material: phosphor bronze
Operating Force: 1.6N
Kind of toggle: round
Contact plating: gold-plated
Max. contact resistance:: 80mΩ
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Body dimensions: 8.5x9x5.55mm
Number of terminals: 5
кількість в упаковці: 1 шт
товар відсутній
G3T22AB-S NKK SWITCHES G3toggles.pdf G3T22AB-S Toggle Switches
товар відсутній
G3T22AH G3T22AH NKK SWITCHES G3Tseries.pdf Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-ON; 0.01A/28VAC; 0.01A/28VDC; G3T
Type of switch: toggle
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-ON
Leads: for PCB
Operating temperature: -30...85°C
Body dimensions: 8.5x9x5mm
Min. insulation resistance: 500MΩ
Max. contact resistance:: 80mΩ
Manufacturer series: G3T
Electrical life: 50000 cycles
Mechanical durability: 50000 cycles
Knob height: 3.8mm
Stable positions number: 2
кількість в упаковці: 1 шт
на замовлення 50 шт:
термін постачання 14-21 дні (днів)
1+497.28 грн
3+ 375.4 грн
8+ 341.78 грн
G3T22AP NKK SWITCHES G3toggles.pdf G3T22AP Toggle Switches
на замовлення 167 шт:
термін постачання 14-21 дні (днів)
1+451.2 грн
4+ 328.54 грн
9+ 310.62 грн
G3T23AH NKK SWITCHES G3T12AB-S.pdf Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DP3T; ON-OFF-ON; 0.1A/28VAC; 0.1A/28VDC
Mounting: SMD
Operating temperature: -30...85°C
Manufacturer series: G3T
Leads: Gull Wing
Number of terminals: 6
Electrical life: 50000 cycles
Body material: PPS
Poles number: 2
Contact material: phosphor bronze
Type of switch: toggle
Contacts configuration: DP3T
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-OFF-ON
Stable positions number: 3
Operating Force: 1.7N
Illumination: none
Kind of toggle: round
Lever length: 3.8mm
Number of positions: 3
Contact plating: gold-plated
Mechanical durability: 50000 cycles
Max. contact resistance:: 80mΩ
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Body dimensions: 8.5x9x5.55mm
кількість в упаковці: 1 шт
товар відсутній
G3T29AB-S NKK SWITCHES G3toggles.pdf G3T29AB-S Toggle Switches
товар відсутній
G3T29AH NKK SWITCHES G3Toggles.pdf G3T29AH Toggle Switches
товар відсутній
GB15AH GB15AH NKK SWITCHES GBseries.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for soldering; right
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 7x7x4.5mm
Manufacturer series: GB
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 123 шт:
термін постачання 14-21 дні (днів)
1+355.2 грн
4+ 335.28 грн
9+ 305.25 грн
25+ 300.41 грн
50+ 293.28 грн
GB15AP GB15AP NKK SWITCHES GBseries.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for soldering
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 7x7x4.5mm
Manufacturer series: GB
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 236 шт:
термін постачання 14-21 дні (днів)
1+355.2 грн
4+ 283.84 грн
11+ 258.42 грн
GB15AV GB15AV NKK SWITCHES GBseries.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for soldering
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 7.4x5x5.3mm
Manufacturer series: GB
Stable positions number: 1
кількість в упаковці: 1 шт
товар відсутній
GB15JHC NKK SWITCHES GB_Illum.pdf GB15JHC Standard Switches
товар відсутній
GB15JHD NKK SWITCHES GB_Illum.pdf GB15JHD Standard Switches
товар відсутній
GB15JHF NKK SWITCHES GB15JHC.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Type of switch: push-button
Contacts configuration: SPDT
Number of positions: 2
DC contacts rating @R: 0.1A / 28V DC
AC contacts rating @R: 0.1A / 28V AC
Mounting: THT
Illumination: LED
Operating Force: 1.7N
Body material: polyamide
Body dimensions: 7.8x7.6x4.9mm
Switching method: ON-(ON)
Operating temperature: -25...55°C
Button shape: round
Key stroke: 1.1mm
Leads: angled; for soldering
Contact material: phosphor bronze
Max. contact resistance:: 80mΩ
Min. insulation resistance: 500MΩ
Contact plating: gold-plated
Mechanical durability: 50000 cycles
Electrical life: 50000 cycles
Manufacturer series: GB
Number of terminals: 5
Body colour: black
Poles number: 1
Stable positions number: 1
Kind of material: fiber glass reinforced
кількість в упаковці: 1 шт
товар відсутній
GB15JPC NKK SWITCHES GB_Illum.pdf GB15JPC Standard Switches
товар відсутній
GB15JPD NKK SWITCHES GB15JHC.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Contact plating: gold-plated
Manufacturer series: GB
Poles number: 1
Contact material: phosphor bronze
Type of switch: push-button
Contacts configuration: SPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-(ON)
Stable positions number: 1
Operating Force: 1.7N
Illumination: LED
Body colour: black
Key stroke: 1.1mm
Button shape: round
Number of positions: 2
Kind of material: fiber glass reinforced
Mounting: THT
Mechanical durability: 50000 cycles
Max. contact resistance:: 80mΩ
Min. insulation resistance: 500MΩ
Operating temperature: -25...55°C
Body dimensions: 4.5x7x7mm
Leads: for soldering; straight
Number of terminals: 5
Electrical life: 50000 cycles
Body material: polyamide
кількість в упаковці: 1 шт
товар відсутній
GB15JPF NKK SWITCHES GB_Illum.pdf GB15JPF Standard Switches
товар відсутній
GB15JVC NKK SWITCHES GB15JHC.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Operating temperature: -25...55°C
Min. insulation resistance: 500MΩ
Mounting: THT
Manufacturer series: GB
Contacts configuration: SPDT
Stable positions number: 1
Number of terminals: 5
Leads: angled; for soldering
Operating Force: 1.7N
Body material: polyamide
Key stroke: 1.1mm
Body dimensions: 5.3x7.6x7.4mm
Switching method: ON-(ON)
Kind of material: fiber glass reinforced
Max. contact resistance:: 80mΩ
Electrical life: 50000 cycles
Illumination: LED
Number of positions: 2
Contact plating: gold-plated
Contact material: phosphor bronze
Poles number: 1
Type of switch: push-button
Mechanical durability: 50000 cycles
DC contacts rating @R: 0.1A / 28V DC
Body colour: black
AC contacts rating @R: 0.1A / 28V AC
Button shape: round
кількість в упаковці: 1 шт
товар відсутній
GB15JVF GB15JVF NKK SWITCHES GBseries.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Operating temperature: -30...85°C
Min. insulation resistance: 500MΩ
Manufacturer series: GB
Contacts configuration: SPDT
Stable positions number: 1
Leads: for soldering
Body dimensions: 7.4x5x5.3mm
Switching method: ON-(ON)
Max. contact resistance:: 80mΩ
Electrical life: 50000 cycles
Number of positions: 2
Type of switch: push-button
Mechanical durability: 50000 cycles
DC contacts rating @R: 0.01A / 28V DC
AC contacts rating @R: 0.01A / 28V AC
кількість в упаковці: 1 шт
на замовлення 100 шт:
термін постачання 14-21 дні (днів)
1+590.4 грн
3+ 446.66 грн
7+ 406.65 грн
GB215A2H GB215A2H NKK SWITCHES GBseries.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for soldering
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 7x7x4.5mm
Manufacturer series: GB
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 50 шт:
термін постачання 14-21 дні (днів)
1+355.2 грн
4+ 287.56 грн
11+ 261.81 грн
GB215AB NKK SWITCHES GB215AB.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPST-NC; 0.1A/28VAC; 0.1A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPST-NC
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: OFF-(ON)
Illumination: none
Leads: for soldering; straight
Operating temperature: -25...70°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 1N
Mechanical durability: 50000 cycles
Button shape: rectangular
Body material: polyamide
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mounting: THT
Body dimensions: 2.5x7.6x7mm
Number of terminals: 2
Manufacturer series: GB2
Stable positions number: 1
Key stroke: 1.1mm
Poles number: 1
Kind of material: fiber glass reinforced
кількість в упаковці: 1 шт
товар відсутній
GB215AH GB215AH NKK SWITCHES GBseries.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for soldering; right
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 7x7x4.5mm
Manufacturer series: GB
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 100 шт:
термін постачання 14-21 дні (днів)
2+255.36 грн
7+ 159.59 грн
19+ 145.3 грн
Мінімальне замовлення: 2
GB215AP GB215AP NKK SWITCHES GBseries.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for soldering
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 7x7x4.5mm
Manufacturer series: GB
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 55 шт:
термін постачання 14-21 дні (днів)
2+255.36 грн
8+ 140.44 грн
22+ 127.87 грн
Мінімальне замовлення: 2
GB25AH GB25AH NKK SWITCHES GBseries.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for soldering; right
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 7x7x4.5mm
Manufacturer series: GB
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 44 шт:
термін постачання 14-21 дні (днів)
1+528.96 грн
3+ 384.95 грн
8+ 350.47 грн
GB25AP GB25AP NKK SWITCHES GBseries.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for soldering
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 7x7x4.5mm
Manufacturer series: GB
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 86 шт:
термін постачання 14-21 дні (днів)
1+528.96 грн
4+ 344.68 грн
9+ 313.81 грн
GB25AV NKK SWITCHES GB25AV.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-(ON)
Illumination: none
Leads: angled; for soldering
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 1.7N
Mechanical durability: 50000 cycles
Button shape: round
Body colour: black
Body material: polyamide
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mounting: THT
Body dimensions: 5.3x7.6x7.4mm
Number of terminals: 6
Manufacturer series: GB
Stable positions number: 1
Key stroke: 1.1mm
Poles number: 2
Kind of material: fiber glass reinforced
кількість в упаковці: 1 шт
товар відсутній
GW12LBH NKK SWITCHES GW12LBH.pdf Category: Rocker Switches
Description: ROCKER; SPDT; Pos: 2; ON-ON; 0.1A/28VAC; 0.1A/28VDC; white; none
Operating temperature: -30...85°C
Manufacturer series: GW
Mounting: THT
Number of terminals: 5
Mechanical durability: 50000 cycles
DC contacts rating @R: 0.1A / 28V DC
Body colour: black
AC contacts rating @R: 0.1A / 28V AC
Key button colour: white
Contacts configuration: SPDT
Stable positions number: 2
Leads: angled; for soldering
Operating Force: 1.3N
Body material: polyamide
Body dimensions: 7.5x7.68x5.15mm
Switching method: ON-ON
Min. insulation resistance: 500MΩ
Kind of material: fiber glass reinforced
Max. contact resistance:: 80mΩ
Electrical life: 50000 cycles
Illumination: none
Number of positions: 2
Contact plating: gold-plated
Terminal pitch: 2.54mm
Contact material: phosphor bronze
Poles number: 1
Button shape: rectangular
Type of switch: ROCKER
кількість в упаковці: 1 шт
товар відсутній
GW12LBP NKK SWITCHES GW12LBH.pdf Category: Rocker Switches
Description: ROCKER; SPDT; Pos: 2; ON-ON; 0.1A/28VAC; 0.1A/28VDC; white; none
Body material: polyamide
Manufacturer series: GW
Poles number: 1
Operating temperature: -30...85°C
Kind of material: fiber glass reinforced
Max. contact resistance:: 80mΩ
Electrical life: 50000 cycles
Illumination: none
Number of positions: 2
Contact plating: gold-plated
Terminal pitch: 2.54mm
Mounting: THT
Contact material: phosphor bronze
Button shape: rectangular
Type of switch: ROCKER
Mechanical durability: 50000 cycles
DC contacts rating @R: 0.1A / 28V DC
Body colour: black
AC contacts rating @R: 0.1A / 28V AC
Key button colour: white
Contacts configuration: SPDT
Stable positions number: 2
Number of terminals: 5
Leads: for soldering; straight
Operating Force: 1.3N
Body dimensions: 4.5x7x7mm
Switching method: ON-ON
Min. insulation resistance: 500MΩ
кількість в упаковці: 1 шт
товар відсутній
GW12LCH NKK SWITCHES GW12LBH.pdf Category: Rocker Switches
Description: ROCKER; SPDT; Pos: 2; ON-ON; 0.1A/28VAC; 0.1A/28VDC; red; none; THT
Body material: polyamide
Manufacturer series: GW
Poles number: 1
Operating temperature: -30...85°C
Kind of material: fiber glass reinforced
Max. contact resistance:: 80mΩ
Electrical life: 50000 cycles
Illumination: none
Number of positions: 2
Contact plating: gold-plated
Terminal pitch: 2.54mm
Mounting: THT
Contact material: phosphor bronze
Button shape: rectangular
Type of switch: ROCKER
Mechanical durability: 50000 cycles
DC contacts rating @R: 0.1A / 28V DC
Body colour: black
AC contacts rating @R: 0.1A / 28V AC
Key button colour: red
Contacts configuration: SPDT
Stable positions number: 2
Number of terminals: 5
Leads: angled; for soldering
Operating Force: 1.3N
Body dimensions: 7.5x7.68x5.15mm
Switching method: ON-ON
Min. insulation resistance: 500MΩ
кількість в упаковці: 1 шт
товар відсутній
G15AH G12AV.pdf
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPDT; ON-(ON); 0.1A/28VAC; 0.1A/28VDC; THT
Mounting: THT
Operating temperature: -25...85°C
Manufacturer series: G
AC contacts rating @R: 0.1A / 28V AC
Lever length: 3.8mm
Contacts configuration: SPDT
Stable positions number: 1
Number of terminals: 5
Leads: angled; for soldering
Operating Force: 0.93N
Body material: polyamide
Body dimensions: 7x7.6x4.9mm
Kind of toggle: round
Switching method: ON-(ON)
Min. insulation resistance: 500MΩ
Kind of material: fiber glass reinforced
Max. contact resistance:: 80mΩ
Electrical life: 50000 cycles
Illumination: none
Number of positions: 2
Actuator material: polyamide
Contact plating: gold-plated
Terminal pitch: 2.54mm
Contact material: phosphor bronze
Poles number: 1
Type of switch: toggle
Mechanical durability: 50000 cycles
DC contacts rating @R: 0.1A / 28V DC
кількість в упаковці: 1 шт
товар відсутній
G18AH G12AV.pdf
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; (ON)-OFF-(ON); 0.1A/28VAC; 0.1A/28VDC
Type of switch: toggle
Contacts configuration: SP3T
Illumination: none
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: (ON)-OFF-(ON)
Mechanical durability: 50000 cycles
Mounting: THT
Number of positions: 3
Operating temperature: -25...85°C
Leads: angled; for soldering
Electrical life: 50000 cycles
Lever length: 3.8mm
Manufacturer series: G
Stable positions number: 1
Body material: polyamide
Poles number: 1
Contact material: phosphor bronze
Actuator material: polyamide
Operating Force: 0.93N
Kind of toggle: round
Kind of material: fiber glass reinforced
Contact plating: gold-plated
Max. contact resistance:: 80mΩ
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Body dimensions: 7x7.6x4.9mm
Number of terminals: 5
кількість в упаковці: 1 шт
товар відсутній
G18AP Gtoggles.pdf
Виробник: NKK SWITCHES
G18AP Toggle Switches
товар відсутній
G18AV Gtoggles.pdf
Виробник: NKK SWITCHES
G18AV Toggle Switches
товар відсутній
G18KP G12KP.pdf
Виробник: NKK SWITCHES
Category: Rocker Switches
Description: ROCKER; SP3T; Pos: 3; (ON)-OFF-(ON); 0.1A/28VAC; 0.1A/28VDC; none
Operating temperature: -25...85°C
Body material: polyamide
Manufacturer series: G
Mounting: THT
Operating Force: 0.81N
Body dimensions: 4.5x7x7mm
Switching method: (ON)-OFF-(ON)
Min. insulation resistance: 500MΩ
Kind of material: fiber glass reinforced
Max. contact resistance:: 80mΩ
Electrical life: 50000 cycles
Illumination: none
Number of positions: 3
Contact plating: gold-plated
Terminal pitch: 2.54mm
Contact material: phosphor bronze
Poles number: 1
Type of switch: ROCKER
Mechanical durability: 50000 cycles
DC contacts rating @R: 0.1A / 28V DC
Body colour: black
AC contacts rating @R: 0.1A / 28V AC
Contacts configuration: SP3T
Stable positions number: 1
Number of terminals: 5
Leads: for soldering; straight
кількість в упаковці: 1 шт
товар відсутній
G19AH Gtoggles.pdf
Виробник: NKK SWITCHES
G19AH Toggle Switches
товар відсутній
G22AH G12AV.pdf
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-ON; 0.1A/28VAC; 0.1A/28VDC; THT
Type of switch: toggle
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-ON
Number of terminals: 6
Mounting: THT
Leads: angled; for soldering
Operating temperature: -25...85°C
Body dimensions: 7x7.6x4.9mm
Min. insulation resistance: 500MΩ
Max. contact resistance:: 80mΩ
Manufacturer series: G
Electrical life: 100000 cycles
Contact plating: gold-plated
Terminal pitch: 2.54mm
Contact material: phosphor bronze
Mechanical durability: 100000 cycles
Illumination: none
Operating Force: 1.2N
Body material: polyamide
Actuator material: polyamide
Poles number: 2
Kind of material: fiber glass reinforced
Stable positions number: 2
Kind of toggle: round
Lever length: 3.8mm
кількість в упаковці: 1 шт
товар відсутній
G22AP Gtoggles.pdf
G22AP
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-ON; 0.1A/28VAC; 0.1A/28VDC; THT
Type of switch: toggle
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-ON
Illumination: none
Leads: for soldering; straight
Operating temperature: -25...85°C
Electrical life: 100000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 1.2N
Mechanical durability: 100000 cycles
Body material: polyamide
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Mounting: THT
Body dimensions: 4.5x7x7mm
Number of terminals: 6
Manufacturer series: G
Stable positions number: 2
Poles number: 2
Kind of material: fiber glass reinforced
Lever length: 3.8mm
Kind of toggle: round
Actuator material: polyamide
на замовлення 92 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
1+412.8 грн
4+ 312.99 грн
9+ 284.95 грн
G22AV Gtoggles.pdf
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-ON; 0.1A/28VAC; 0.1A/28VDC; THT
Type of switch: toggle
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-ON
Illumination: none
Leads: angled; for soldering
Operating temperature: -25...85°C
Electrical life: 100000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 1.2N
Mechanical durability: 100000 cycles
Body material: polyamide
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Mounting: THT
Body dimensions: 5.3x7.6x7.4mm
Number of terminals: 6
Manufacturer series: G
Stable positions number: 2
Poles number: 2
Kind of material: fiber glass reinforced
Lever length: 3.8mm
Kind of toggle: round
Actuator material: polyamide
товар відсутній
G22KP GRocker-1.pdf
Виробник: NKK SWITCHES
Category: Rocker Switches
Description: ROCKER; DPDT; Pos: 2; ON-ON; 0.1A/28VAC; 0.1A/28VDC; none; -25÷85°C
Type of switch: ROCKER
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-ON
Illumination: none
Leads: for soldering; straight
Operating temperature: -25...85°C
Electrical life: 100000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 1.06N
Mechanical durability: 100000 cycles
Body colour: black
Body material: polyamide
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Mounting: THT
Body dimensions: 4.5x7x7mm
Number of terminals: 6
Manufacturer series: G
Stable positions number: 2
Poles number: 2
Kind of material: fiber glass reinforced
товар відсутній
G23AH G12AV.pdf
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DP3T; ON-OFF-ON; 0.1A/28VAC; 0.1A/28VDC
Type of switch: toggle
Number of positions: 3
Contacts configuration: DP3T
Switching method: ON-OFF-ON
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Leads: angled; for soldering
Number of terminals: 6
Terminal pitch: 2.54mm
Operating temperature: -25...85°C
Kind of toggle: round
Max. contact resistance:: 80mΩ
Body dimensions: 7x7.6x4.9mm
Electrical life: 100000 cycles
Actuator material: polyamide
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mechanical durability: 100000 cycles
Contact material: phosphor bronze
Mounting: THT
Body material: polyamide
Illumination: none
Operating Force: 1.2N
Poles number: 2
Lever length: 3.8mm
Manufacturer series: G
Kind of material: fiber glass reinforced
Stable positions number: 3
кількість в упаковці: 1 шт
товар відсутній
G23AP Gtoggles.pdf
G23AP
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DP3T; ON-OFF-ON; 0.1A/28VAC; 0.1A/28VDC
Type of switch: toggle
Number of positions: 3
Contacts configuration: DP3T
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-OFF-ON
Illumination: none
Leads: for soldering; straight
Operating temperature: -25...85°C
Electrical life: 100000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 1.2N
Mechanical durability: 100000 cycles
Body material: polyamide
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Mounting: THT
Body dimensions: 4.5x7x7mm
Number of terminals: 6
Manufacturer series: G
Stable positions number: 3
Poles number: 2
Kind of material: fiber glass reinforced
Lever length: 3.8mm
Kind of toggle: round
Actuator material: polyamide
товар відсутній
G23AV Gtoggles.pdf
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DP3T; ON-OFF-ON; 0.1A/28VAC; 0.1A/28VDC
Type of switch: toggle
Number of positions: 3
Contacts configuration: DP3T
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-OFF-ON
Illumination: none
Leads: angled; for soldering
Operating temperature: -25...85°C
Electrical life: 100000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 1.2N
Mechanical durability: 100000 cycles
Body material: polyamide
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Mounting: THT
Body dimensions: 5.3x7.6x7.4mm
Number of terminals: 6
Manufacturer series: G
Stable positions number: 3
Poles number: 2
Kind of material: fiber glass reinforced
Lever length: 3.8mm
Kind of toggle: round
Actuator material: polyamide
товар відсутній
G23KP GRocker-1.pdf
Виробник: NKK SWITCHES
Category: Rocker Switches
Description: ROCKER; DP3T; Pos: 3; ON-OFF-ON; 0.1A/28VAC; 0.1A/28VDC; none; THT
Type of switch: ROCKER
Number of positions: 3
Contacts configuration: DP3T
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-OFF-ON
Illumination: none
Leads: for soldering; straight
Operating temperature: -25...85°C
Electrical life: 100000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 1.06N
Mechanical durability: 100000 cycles
Body colour: black
Body material: polyamide
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Mounting: THT
Body dimensions: 4.5x7x7mm
Number of terminals: 6
Manufacturer series: G
Stable positions number: 3
Poles number: 2
Kind of material: fiber glass reinforced
товар відсутній
G29AH Gtoggles.pdf
Виробник: NKK SWITCHES
G29AH Toggle Switches
товар відсутній
G29AP Gtoggles.pdf
Виробник: NKK SWITCHES
G29AP Toggle Switches
товар відсутній
G3B15AB G3B15AB.pdf
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-(ON)
Illumination: none
Leads: Gull Wing
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 2N
Mechanical durability: 50000 cycles
Button shape: round
Body material: PPS
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mounting: SMD
Body dimensions: 5x11x9mm
Number of terminals: 3
Manufacturer series: G3B
Stable positions number: 1
Key stroke: 1.1mm
Poles number: 1
кількість в упаковці: 1 шт
товар відсутній
G3B15AB-S G3B15AB.pdf
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-(ON)
Illumination: none
Leads: Gull Wing
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 2N
Mechanical durability: 50000 cycles
Button shape: round
Body material: PPS
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mounting: SMD
Body dimensions: 5x11x9mm
Number of terminals: 3
Manufacturer series: G3B
Stable positions number: 1
Key stroke: 1.1mm
Poles number: 1
кількість в упаковці: 1 шт
товар відсутній
G3B15AH G3Bseries.pdf
G3B15AH
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for PCB; right
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 9x8.5x5mm
Manufacturer series: G3B
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 116 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
1+492.48 грн
3+ 418.74 грн
8+ 381.24 грн
G3B15AH-R G3B15AB.pdf G3Bseries.pdf
G3B15AH-R
+1
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for PCB; right
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 9x8.5x5mm
Manufacturer series: G3B
Kind of package: reel
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 500 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
1+519.36 грн
3+ 418.74 грн
8+ 381.24 грн
100+ 377.07 грн
G3B15AP G3Bseries.pdf
G3B15AP
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for PCB
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 9x8.5x5mm
Manufacturer series: G3B
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 132 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
1+497.28 грн
3+ 379.7 грн
8+ 345.69 грн
G3B25AB-S G3B15AB.pdf
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-(ON)
Illumination: none
Leads: Gull Wing
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 2N
Mechanical durability: 50000 cycles
Button shape: round
Body material: PPS
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mounting: SMD
Body dimensions: 5x11x9mm
Number of terminals: 6
Manufacturer series: G3B
Stable positions number: 1
Key stroke: 1.1mm
Poles number: 2
кількість в упаковці: 1 шт
товар відсутній
G3B25AH G3B15AB.pdf
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-(ON)
Illumination: none
Leads: Gull Wing
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 2N
Mechanical durability: 50000 cycles
Button shape: round
Body material: PPS
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mounting: SMD
Body dimensions: 8.5x9x5.55mm
Number of terminals: 6
Manufacturer series: G3B
Stable positions number: 1
Key stroke: 1.1mm
Poles number: 2
кількість в упаковці: 1 шт
товар відсутній
G3B25AP G3B25AP.pdf
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-(ON)
Illumination: none
Leads: Gull Wing
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 2N
Mechanical durability: 50000 cycles
Button shape: round
Body material: PPS
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mounting: SMD
Body dimensions: 5x11x9mm
Number of terminals: 6
Manufacturer series: G3B
Stable positions number: 1
Key stroke: 1.1mm
Poles number: 2
кількість в упаковці: 1 шт
товар відсутній
G3B25AP-S G3B25AP.pdf
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-(ON)
Illumination: none
Leads: Gull Wing
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 2N
Mechanical durability: 50000 cycles
Button shape: round
Body material: PPS
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mounting: SMD
Body dimensions: 5x11x9mm
Number of terminals: 6
Manufacturer series: G3B
Stable positions number: 1
Key stroke: 1.1mm
Poles number: 2
кількість в упаковці: 1 шт
товар відсутній
G3T12AB-S G3T12AB-S.pdf
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPDT; ON-ON; 0.1A/28VAC; 0.1A/28VDC; SMD
Mounting: SMD
Operating temperature: -30...85°C
Manufacturer series: G3T
Lever length: 3.8mm
Contacts configuration: SPDT
Stable positions number: 2
Number of terminals: 5
Leads: Gull Wing
Operating Force: 1.7N
Body material: PPS
Body dimensions: 5x11x9mm
Kind of toggle: round
Switching method: ON-ON
Min. insulation resistance: 500MΩ
Max. contact resistance:: 80mΩ
Electrical life: 50000 cycles
Illumination: none
Number of positions: 2
Contact plating: gold-plated
Terminal pitch: 2.54mm
Contact material: phosphor bronze
Poles number: 1
Type of switch: toggle
Mechanical durability: 50000 cycles
DC contacts rating @R: 0.1A / 28V DC
AC contacts rating @R: 0.1A / 28V AC
кількість в упаковці: 1 шт
товар відсутній
G3T12AH G3Tseries.pdf
G3T12AH
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPDT; ON-ON; 0.01A/28VAC; 0.01A/28VDC; G3T
Operating temperature: -30...85°C
Manufacturer series: G3T
Type of switch: toggle
Contacts configuration: SPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-ON
Stable positions number: 2
Knob height: 3.8mm
Number of positions: 2
Mechanical durability: 50000 cycles
Max. contact resistance:: 80mΩ
Min. insulation resistance: 500MΩ
Body dimensions: 8.5x9x5mm
Leads: for PCB
Electrical life: 50000 cycles
кількість в упаковці: 1 шт
на замовлення 42 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
1+355.2 грн
4+ 313.08 грн
10+ 285.03 грн
100+ 283.47 грн
G3T12AH-R G3T12AB-S.pdf G3Tseries.pdf
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: toggle; Pos: 2; SPDT; 0.01A/28VAC; 0.01A/28VDC; ON-ON; 500MΩ
Operating temperature: -30...85°C
Manufacturer series: G3T
Type of switch: toggle
Contacts configuration: SPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-ON
Stable positions number: 2
Knob height: 3.8mm
Number of positions: 2
Mechanical durability: 50000 cycles
Max. contact resistance:: 80mΩ
Min. insulation resistance: 500MΩ
Body dimensions: 8.5x9x5mm
Leads: for PCB
Electrical life: 50000 cycles
кількість в упаковці: 1 шт
товар відсутній
G3T12AP G3T12AB-S.pdf
G3T12AP
+1
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPDT; ON-ON; 0.1A/28VAC; 0.1A/28VDC; 8.5x5mm
Operating temperature: -30...85°C
Contacts configuration: SPDT
Stable positions number: 2
Leads: for soldering
Kind of toggle: round
Switching method: ON-ON
Electrical life: 50000 cycles
Number of positions: 2
Mounting hole diameter: 8.5x5mm
Type of switch: toggle
DC contacts rating @R: 0.1A / 28V DC
AC contacts rating @R: 0.1A / 28V AC
кількість в упаковці: 1 шт
на замовлення 170 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
1+398.4 грн
4+ 269.79 грн
11+ 245.62 грн
G3T13AB G3T12AB-S.pdf
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; ON-OFF-ON; 0.1A/28VAC; 0.1A/28VDC
Type of switch: toggle
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Contacts configuration: SP3T
Max. contact resistance:: 80mΩ
Switching method: ON-OFF-ON
Number of positions: 3
Stable positions number: 3
Leads: Gull Wing
Body dimensions: 5x11x9mm
Mechanical durability: 50000 cycles
Operating temperature: -30...85°C
Operating Force: 1.7N
Lever length: 3.8mm
Electrical life: 50000 cycles
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Contact material: phosphor bronze
Body material: PPS
Mounting: SMD
Illumination: none
Manufacturer series: G3T
Number of terminals: 5
Poles number: 1
Kind of toggle: round
кількість в упаковці: 1 шт
товар відсутній
G3T13AH G3T12AB-S.pdf
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; ON-OFF-ON; 0.1A/28VAC; 0.1A/28VDC
Type of switch: toggle
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Contacts configuration: SP3T
Max. contact resistance:: 80mΩ
Switching method: ON-OFF-ON
Number of positions: 3
Stable positions number: 3
Leads: Gull Wing
Body dimensions: 8.5x9x5.55mm
Mechanical durability: 50000 cycles
Operating temperature: -30...85°C
Operating Force: 1.7N
Lever length: 3.8mm
Electrical life: 50000 cycles
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Contact material: phosphor bronze
Body material: PPS
Mounting: SMD
Illumination: none
Manufacturer series: G3T
Number of terminals: 5
Poles number: 1
Kind of toggle: round
кількість в упаковці: 1 шт
товар відсутній
G3T13AP G3T12AB-S.pdf
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; ON-OFF-ON; 0.1A/28VAC; 0.1A/28VDC
Type of switch: toggle
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Contacts configuration: SP3T
Max. contact resistance:: 80mΩ
Switching method: ON-OFF-ON
Number of positions: 3
Stable positions number: 3
Leads: Gull Wing
Body dimensions: 5x8.5x9mm
Mechanical durability: 50000 cycles
Operating temperature: -30...85°C
Operating Force: 1.7N
Lever length: 3.8mm
Electrical life: 50000 cycles
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Contact material: phosphor bronze
Body material: PPS
Mounting: SMD
Illumination: none
Manufacturer series: G3T
Number of terminals: 5
Poles number: 1
Kind of toggle: round
кількість в упаковці: 1 шт
товар відсутній
G3T18AH G3T12AB-S.pdf
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; SP3T; (ON)-OFF-(ON); 0.1A/28VAC; 0.1A/28VDC
Type of switch: toggle
Contacts configuration: SP3T
Illumination: none
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: (ON)-OFF-(ON)
Mechanical durability: 50000 cycles
Mounting: SMD
Number of positions: 3
Operating temperature: -30...85°C
Leads: Gull Wing
Electrical life: 50000 cycles
Lever length: 3.8mm
Manufacturer series: G3T
Stable positions number: 1
Body material: PPS
Poles number: 1
Contact material: phosphor bronze
Operating Force: 1.6N
Kind of toggle: round
Contact plating: gold-plated
Max. contact resistance:: 80mΩ
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Body dimensions: 8.5x9x5.55mm
Number of terminals: 5
кількість в упаковці: 1 шт
товар відсутній
G3T22AB-S G3toggles.pdf
Виробник: NKK SWITCHES
G3T22AB-S Toggle Switches
товар відсутній
G3T22AH G3Tseries.pdf
G3T22AH
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-ON; 0.01A/28VAC; 0.01A/28VDC; G3T
Type of switch: toggle
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-ON
Leads: for PCB
Operating temperature: -30...85°C
Body dimensions: 8.5x9x5mm
Min. insulation resistance: 500MΩ
Max. contact resistance:: 80mΩ
Manufacturer series: G3T
Electrical life: 50000 cycles
Mechanical durability: 50000 cycles
Knob height: 3.8mm
Stable positions number: 2
кількість в упаковці: 1 шт
на замовлення 50 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
1+497.28 грн
3+ 375.4 грн
8+ 341.78 грн
G3T22AP G3toggles.pdf
Виробник: NKK SWITCHES
G3T22AP Toggle Switches
на замовлення 167 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
1+451.2 грн
4+ 328.54 грн
9+ 310.62 грн
G3T23AH G3T12AB-S.pdf
Виробник: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DP3T; ON-OFF-ON; 0.1A/28VAC; 0.1A/28VDC
Mounting: SMD
Operating temperature: -30...85°C
Manufacturer series: G3T
Leads: Gull Wing
Number of terminals: 6
Electrical life: 50000 cycles
Body material: PPS
Poles number: 2
Contact material: phosphor bronze
Type of switch: toggle
Contacts configuration: DP3T
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-OFF-ON
Stable positions number: 3
Operating Force: 1.7N
Illumination: none
Kind of toggle: round
Lever length: 3.8mm
Number of positions: 3
Contact plating: gold-plated
Mechanical durability: 50000 cycles
Max. contact resistance:: 80mΩ
Min. insulation resistance: 500MΩ
Terminal pitch: 2.54mm
Body dimensions: 8.5x9x5.55mm
кількість в упаковці: 1 шт
товар відсутній
G3T29AB-S G3toggles.pdf
Виробник: NKK SWITCHES
G3T29AB-S Toggle Switches
товар відсутній
G3T29AH G3Toggles.pdf
Виробник: NKK SWITCHES
G3T29AH Toggle Switches
товар відсутній
GB15AH GBseries.pdf
GB15AH
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for soldering; right
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 7x7x4.5mm
Manufacturer series: GB
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 123 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
1+355.2 грн
4+ 335.28 грн
9+ 305.25 грн
25+ 300.41 грн
50+ 293.28 грн
GB15AP GBseries.pdf
GB15AP
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for soldering
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 7x7x4.5mm
Manufacturer series: GB
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 236 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
1+355.2 грн
4+ 283.84 грн
11+ 258.42 грн
GB15AV GBseries.pdf
GB15AV
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for soldering
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 7.4x5x5.3mm
Manufacturer series: GB
Stable positions number: 1
кількість в упаковці: 1 шт
товар відсутній
GB15JHC GB_Illum.pdf
Виробник: NKK SWITCHES
GB15JHC Standard Switches
товар відсутній
GB15JHD GB_Illum.pdf
Виробник: NKK SWITCHES
GB15JHD Standard Switches
товар відсутній
GB15JHF GB15JHC.pdf
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Type of switch: push-button
Contacts configuration: SPDT
Number of positions: 2
DC contacts rating @R: 0.1A / 28V DC
AC contacts rating @R: 0.1A / 28V AC
Mounting: THT
Illumination: LED
Operating Force: 1.7N
Body material: polyamide
Body dimensions: 7.8x7.6x4.9mm
Switching method: ON-(ON)
Operating temperature: -25...55°C
Button shape: round
Key stroke: 1.1mm
Leads: angled; for soldering
Contact material: phosphor bronze
Max. contact resistance:: 80mΩ
Min. insulation resistance: 500MΩ
Contact plating: gold-plated
Mechanical durability: 50000 cycles
Electrical life: 50000 cycles
Manufacturer series: GB
Number of terminals: 5
Body colour: black
Poles number: 1
Stable positions number: 1
Kind of material: fiber glass reinforced
кількість в упаковці: 1 шт
товар відсутній
GB15JPC GB_Illum.pdf
Виробник: NKK SWITCHES
GB15JPC Standard Switches
товар відсутній
GB15JPD GB15JHC.pdf
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Contact plating: gold-plated
Manufacturer series: GB
Poles number: 1
Contact material: phosphor bronze
Type of switch: push-button
Contacts configuration: SPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-(ON)
Stable positions number: 1
Operating Force: 1.7N
Illumination: LED
Body colour: black
Key stroke: 1.1mm
Button shape: round
Number of positions: 2
Kind of material: fiber glass reinforced
Mounting: THT
Mechanical durability: 50000 cycles
Max. contact resistance:: 80mΩ
Min. insulation resistance: 500MΩ
Operating temperature: -25...55°C
Body dimensions: 4.5x7x7mm
Leads: for soldering; straight
Number of terminals: 5
Electrical life: 50000 cycles
Body material: polyamide
кількість в упаковці: 1 шт
товар відсутній
GB15JPF GB_Illum.pdf
Виробник: NKK SWITCHES
GB15JPF Standard Switches
товар відсутній
GB15JVC GB15JHC.pdf
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Operating temperature: -25...55°C
Min. insulation resistance: 500MΩ
Mounting: THT
Manufacturer series: GB
Contacts configuration: SPDT
Stable positions number: 1
Number of terminals: 5
Leads: angled; for soldering
Operating Force: 1.7N
Body material: polyamide
Key stroke: 1.1mm
Body dimensions: 5.3x7.6x7.4mm
Switching method: ON-(ON)
Kind of material: fiber glass reinforced
Max. contact resistance:: 80mΩ
Electrical life: 50000 cycles
Illumination: LED
Number of positions: 2
Contact plating: gold-plated
Contact material: phosphor bronze
Poles number: 1
Type of switch: push-button
Mechanical durability: 50000 cycles
DC contacts rating @R: 0.1A / 28V DC
Body colour: black
AC contacts rating @R: 0.1A / 28V AC
Button shape: round
кількість в упаковці: 1 шт
товар відсутній
GB15JVF GBseries.pdf
GB15JVF
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Operating temperature: -30...85°C
Min. insulation resistance: 500MΩ
Manufacturer series: GB
Contacts configuration: SPDT
Stable positions number: 1
Leads: for soldering
Body dimensions: 7.4x5x5.3mm
Switching method: ON-(ON)
Max. contact resistance:: 80mΩ
Electrical life: 50000 cycles
Number of positions: 2
Type of switch: push-button
Mechanical durability: 50000 cycles
DC contacts rating @R: 0.01A / 28V DC
AC contacts rating @R: 0.01A / 28V AC
кількість в упаковці: 1 шт
на замовлення 100 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
1+590.4 грн
3+ 446.66 грн
7+ 406.65 грн
GB215A2H GBseries.pdf
GB215A2H
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for soldering
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 7x7x4.5mm
Manufacturer series: GB
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 50 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
1+355.2 грн
4+ 287.56 грн
11+ 261.81 грн
GB215AB GB215AB.pdf
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPST-NC; 0.1A/28VAC; 0.1A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: SPST-NC
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: OFF-(ON)
Illumination: none
Leads: for soldering; straight
Operating temperature: -25...70°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 1N
Mechanical durability: 50000 cycles
Button shape: rectangular
Body material: polyamide
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mounting: THT
Body dimensions: 2.5x7.6x7mm
Number of terminals: 2
Manufacturer series: GB2
Stable positions number: 1
Key stroke: 1.1mm
Poles number: 1
Kind of material: fiber glass reinforced
кількість в упаковці: 1 шт
товар відсутній
GB215AH GBseries.pdf
GB215AH
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for soldering; right
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 7x7x4.5mm
Manufacturer series: GB
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 100 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
2+255.36 грн
7+ 159.59 грн
19+ 145.3 грн
Мінімальне замовлення: 2
GB215AP GBseries.pdf
GB215AP
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for soldering
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 7x7x4.5mm
Manufacturer series: GB
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 55 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
2+255.36 грн
8+ 140.44 грн
22+ 127.87 грн
Мінімальне замовлення: 2
GB25AH GBseries.pdf
GB25AH
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for soldering; right
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 7x7x4.5mm
Manufacturer series: GB
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 44 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
1+528.96 грн
3+ 384.95 грн
8+ 350.47 грн
GB25AP GBseries.pdf
GB25AP
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.01A/28VAC; 0.01A/28VDC; 500MΩ
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.01A / 28V AC
DC contacts rating @R: 0.01A / 28V DC
Switching method: ON-(ON)
Leads: for soldering
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Mechanical durability: 50000 cycles
Min. insulation resistance: 500MΩ
Body dimensions: 7x7x4.5mm
Manufacturer series: GB
Stable positions number: 1
кількість в упаковці: 1 шт
на замовлення 86 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна без ПДВ
1+528.96 грн
4+ 344.68 грн
9+ 313.81 грн
GB25AV GB25AV.pdf
Виробник: NKK SWITCHES
Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.1A/28VAC; 0.1A/28VDC; ON-(ON)
Type of switch: push-button
Number of positions: 2
Contacts configuration: DPDT
AC contacts rating @R: 0.1A / 28V AC
DC contacts rating @R: 0.1A / 28V DC
Switching method: ON-(ON)
Illumination: none
Leads: angled; for soldering
Operating temperature: -30...85°C
Electrical life: 50000 cycles
Max. contact resistance:: 80mΩ
Operating Force: 1.7N
Mechanical durability: 50000 cycles
Button shape: round
Body colour: black
Body material: polyamide
Contact material: phosphor bronze
Contact plating: gold-plated
Min. insulation resistance: 500MΩ
Mounting: THT
Body dimensions: 5.3x7.6x7.4mm
Number of terminals: 6
Manufacturer series: GB
Stable positions number: 1
Key stroke: 1.1mm
Poles number: 2
Kind of material: fiber glass reinforced
кількість в упаковці: 1 шт
товар відсутній
GW12LBH GW12LBH.pdf
Виробник: NKK SWITCHES
Category: Rocker Switches
Description: ROCKER; SPDT; Pos: 2; ON-ON; 0.1A/28VAC; 0.1A/28VDC; white; none
Operating temperature: -30...85°C
Manufacturer series: GW
Mounting: THT
Number of terminals: 5
Mechanical durability: 50000 cycles
DC contacts rating @R: 0.1A / 28V DC
Body colour: black
AC contacts rating @R: 0.1A / 28V AC
Key button colour: white
Contacts configuration: SPDT
Stable positions number: 2
Leads: angled; for soldering
Operating Force: 1.3N
Body material: polyamide
Body dimensions: 7.5x7.68x5.15mm
Switching method: ON-ON
Min. insulation resistance: 500MΩ
Kind of material: fiber glass reinforced
Max. contact resistance:: 80mΩ
Electrical life: 50000 cycles
Illumination: none
Number of positions: 2
Contact plating: gold-plated
Terminal pitch: 2.54mm
Contact material: phosphor bronze
Poles number: 1
Button shape: rectangular
Type of switch: ROCKER
кількість в упаковці: 1 шт
товар відсутній
GW12LBP GW12LBH.pdf
Виробник: NKK SWITCHES
Category: Rocker Switches
Description: ROCKER; SPDT; Pos: 2; ON-ON; 0.1A/28VAC; 0.1A/28VDC; white; none
Body material: polyamide
Manufacturer series: GW
Poles number: 1
Operating temperature: -30...85°C
Kind of material: fiber glass reinforced
Max. contact resistance:: 80mΩ
Electrical life: 50000 cycles
Illumination: none
Number of positions: 2
Contact plating: gold-plated
Terminal pitch: 2.54mm
Mounting: THT
Contact material: phosphor bronze
Button shape: rectangular
Type of switch: ROCKER
Mechanical durability: 50000 cycles
DC contacts rating @R: 0.1A / 28V DC
Body colour: black
AC contacts rating @R: 0.1A / 28V AC
Key button colour: white
Contacts configuration: SPDT
Stable positions number: 2
Number of terminals: 5
Leads: for soldering; straight
Operating Force: 1.3N
Body dimensions: 4.5x7x7mm
Switching method: ON-ON
Min. insulation resistance: 500MΩ
кількість в упаковці: 1 шт
товар відсутній
GW12LCH GW12LBH.pdf
Виробник: NKK SWITCHES
Category: Rocker Switches
Description: ROCKER; SPDT; Pos: 2; ON-ON; 0.1A/28VAC; 0.1A/28VDC; red; none; THT
Body material: polyamide
Manufacturer series: GW
Poles number: 1
Operating temperature: -30...85°C
Kind of material: fiber glass reinforced
Max. contact resistance:: 80mΩ
Electrical life: 50000 cycles
Illumination: none
Number of positions: 2
Contact plating: gold-plated
Terminal pitch: 2.54mm
Mounting: THT
Contact material: phosphor bronze
Button shape: rectangular
Type of switch: ROCKER
Mechanical durability: 50000 cycles
DC contacts rating @R: 0.1A / 28V DC
Body colour: black
AC contacts rating @R: 0.1A / 28V AC
Key button colour: red
Contacts configuration: SPDT
Stable positions number: 2
Number of terminals: 5
Leads: angled; for soldering
Operating Force: 1.3N
Body dimensions: 7.5x7.68x5.15mm
Switching method: ON-ON
Min. insulation resistance: 500MΩ
кількість в упаковці: 1 шт
товар відсутній
Обрати Сторінку:   [  << Попередня Сторінка ]  1 72 144 216 288 360 432 504 576 623 624 625 626 627 628 629 630 631 632 633 648 720 728  [ Наступна Сторінка >> ]
