Продукція > AXIOMET > Всі товари виробника AXIOMET (350) > Сторінка 2 з 6

Виробник: AXIOMET
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LCD; 5 digits (80000); Sampling: 4x/s
Type of meter: benchtop multimeter
Interface: RS232
Measurement: AC current; AC voltage; capacitance; continuity; dBm; DC current; DC voltage; frequency; resistance; temperature
Kind of display used: LCD
Display parameters: 5 digits (80000)
Bargraph: 23 segm. 40x/s
Sampling: 4x/s
DC voltage measuring range: 80mV; 800mV; 8V; 80V; 800V; 1kV
DC voltage measuring accuracy: ±(0.05% + 5 digit)
AC voltage measuring range: 80mV; 800mV; 8V; 80V; 750V
AC voltage measuring accuracy: ±(0.8% + 50 digit)
DC current measuring range: 80mA; 800mA; 8A; 20A
DC current measuring accuracy: ±(0.2% + 10 digit)
AC current measuring range: 80mA; 800mA; 8A; 20A
AC current measuring accuracy: ±(0.8% + 20 digit)
True effective value measurement: True RMS
Resistance measuring range: 800Ω; 8kΩ; 80kΩ; 800kΩ; 8MΩ; 80MΩ
Capacitance measuring range: 1nF; 10nF; 100nF; 1µF; 10µF; 100µF
Capacitance measuring accuracy: ±(2.5%+ 50 digit)
Frequency measuring range: 99999mHz; 999.99Hz; 9.9999kHz; 99.999kHz; 999.99kHz; 8MHz
Frequency measuring accuracy: ±(0.05%+5 digit)
Temperature measurement accuracy: ±(2% + 2°C)
Resistance measuring accuracy: ±(0.1%+5 digit)
Continuity test: acoustic indication; <60Ω
Operating temperature: 0...50°C
Dimensions: 225x100x368mm
Standard equipment: drop-like K-type probe; mains cable; RS232 cable; test lead
Optional equipment: test leads AX-TL-4B1-B; test leads AX-TL-4B1-BL; test leads AX-TL-4B1-R; test leads AX-TL-BNC-4BP2; test leads AX-TLP-001; test leads AX-TLP-001T; test leads AX-TLP-002; test leads AX-TLP-003; test leads AX-TLS-001B; test leads AX-TLS-002B; test leads AX-TLS-003A; test leads AX-TLS-004A; test leads AX-TLS-005A; test leads AX-TLS-007S; test leads PPOM-14; test tweezers AX-TLP-TW-01
Conform to the norm: CAT II 1000V; CAT III 600V; EN 61010
Related items: 5790D; 5793D; 5794D; 5795D; 5797D; BKP60; EX871515; EX881602; EX881603; EX881605; PKT-PTA; PKT-PTF-10; PKT-PTF-20; PKT-PTF-25; PKT-PTF-30; PKT-PTF-40; PKT-PTF-50; PKT-PTF-55; PKT-PTF-56; PKT-PTF-60; SE027; SE028; SE029; SE030; SE031; SE059; SE060; SE061; SE062; SE001; SE002; SE003; SE004; SE000; TESTO-06020393; TESTO-06020645; TESTO-06024592; TESTO-06024892; TESTO-06280020; TESTO-06281292; TESTO-06287533; TP200; TP400; TP870; TP873; TP873-5M; TP882; TP-111; TP-112; TP-02; TP-03; TP-04; TP-06; TP-08; TP-09; TPK-59; TPK-62; UTT10K; UTT12
Protection: anti-overload OPP
Additional functions: square waveform generator
Measuring instrument features: AUTO HOLD; PEAK HOLD function; simultaneously displays 2 measurements
Software: compatible Windows 7; compatible Windows 10; compatible Windows 98; compatible Windows 2000; compatible Windows NT; Windows Vista compatible; Windows XP compatible
Supply voltage: 100...240V AC
Max. environment humidity: 75%
Temperature measuring range measured by probe: -50...1372°C

Виробник: AXIOMET
Category: Metals & cables detectors
Description: Non-contact metal and voltage detector; LCD
Kind of display used: LCD
Dimensions: 180x67x38mm
Power supply: battery 6F22 9V x1
Measuring instrument features: 6-metre laser light line; automatic power-off; detectable materials: reinforcing steel, steel, wooden structures, live conductors; ergonomic case ensuring comfortable and precise operation; function of autocalibration for metal and wood detection function; level head rotated by 180° with laser indicators; low battery indicator; optical (LED) and acoustic indication of detected voltage; reinforced enclosure
Battery/ rechargeable battery: battery 6F22 9V x1
Additional functions: laser level; level
Detection: metal; voltage at depth up to 1,9cm; wood
Type of tester: non-contact metal and voltage detector

Виробник: AXIOMET
Category: Temperature Meters
Description: Meter: temperature; digital; LCD; -50÷150°C; Accur: ±1°C
Type of meter: temperature
Kind of meter: digital
Kind of display used: LCD
Temperature measuring range: -50...150°C
Temperature measurement accuracy: ±1°C
Temperature measurement resolution: 0.1°C
Probe length: 250mm
Weight without batteries: 51g
Power supply: battery LR44 1,5V x1
Measuring instrument features: automatic power-off; HOLD function; low battery indicator; MIN/MAX function; pointed probe made of stainless steel
Standard equipment: plastic protecting cap for measurement probe
Measurement: temperature
Measuring unit: °C; °F
Probe diameter: 4mm
Battery/ rechargeable battery: none

Виробник: AXIOMET
Category: Temperature Meters
Description: Meter: temperature; digital; LCD; Accur: ±1°C@(-20°C÷150°C); IP67
Power supply: battery 393 1,5V x1
Standard equipment: clip for attaching the thermometer
Kind of display used: LCD
Measuring instrument features: automatic power-off; HOLD function
Type of meter: temperature
Temperature measurement resolution: 0.1°C
Temperature measuring range measured by probe: -50...150°C
Kind of meter: digital
Temperature measurement accuracy: ±1°C @(-20°C...150°C)
IP rating: IP67

Виробник: AXIOMET
Category: Inspection Cameras, Boroscopes
Description: Inspection camera; Display: LCD 4,3"; Cam.res: 720x480; Len: 0.48m
Type of meter: inspection camera
Kind of display used: LCD 4,3"
Camera resolution: 720x480
IP rating: IP67 (probe)
Measuring instrument features: LED for measurement spot illumination; length of telescopic pole: min. 1,08m, max. 2,85m; low battery indicator; option of memory card connection SD
Standard equipment: battery charger/power supply; hard case; sunshield; telescopic pole to camera
Plug variant: EU
Battery/ rechargeable battery: rechargeable battery Li-Ion x1
Display resolution: 480x272
Supported formats: AVI
Cable length: 0.48m
Probe diameter: 23mm

Виробник: AXIOMET
Category: Inspection Cameras, Boroscopes
Description: Inspection camera; Display: LCD 2,4"; Cam.res: 640x480; Len: 1m
Type of meter: inspection camera
Kind of display used: LCD 2,4"
Camera resolution: 640x480
Cable length: 1m
Probe diameter: 12mm
IP rating: IP67
Dimensions: 266x95x66mm
Power supply: battery LR6 AA 1,5V x4
Measuring instrument features: flexible cord; LED for measurement spot illumination; low battery indicator; TV-Out (NTSC)
Standard equipment: fixtures: mirror, hook, magnet; video cable
Related items: AX-BCX2; AX-BCX3
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Display resolution: 320x240

Виробник: AXIOMET
Category: Inspection Cameras, Boroscopes
Description: Inspection camera; Display: colour,LCD TFT 2,7"; 60°
Type of meter: inspection camera
Kind of display used: colour; LCD TFT 2,7"
Dimensions: 150x73x38mm
Power supply: battery LR03 AAA 1,5V x4
Measuring instrument features: 180° image rotation; digital zoom x4; flexible cord; LED for measurement spot illumination; low battery indicator
Standard equipment: case; fixtures: mirror, hook, magnet; video cable
Battery/ rechargeable battery: none
Display resolution: 320x240
Probe length: 600mm
Probe diameter: 9mm
Viewing angle: 60°

Виробник: AXIOMET
Category: Inspection Cameras, Boroscopes
Description: Inspection camera; Display: LCD 7"; Cam.res: 720x480; Len: 20m
Type of meter: inspection camera
Kind of display used: LCD 7"
Camera resolution: 720x480
IP rating: IP68
Measuring instrument features: AVI recording format; LED for measurement spot illumination; meter markers on video cable; option of memory card connection SD; TV-Out (NTSC)
Standard equipment: battery charger/power supply; stand; sunshield
Battery/ rechargeable battery: rechargeable battery Li-Ion 12V 4400mAh
Plug variant: EU
Manufacturer series: AX-B21XX
Probe diameter: 23mm
Cable length: 20m

Виробник: AXIOMET
Category: Inspection Cameras, Boroscopes
Description: Spare part: display; AX-B2120CW
Related items: AX-B2120CW
Type of spare part: display

Виробник: AXIOMET
Category: Inspection Cameras, Boroscopes
Description: Inspection camera; Display: LCD 7"; Cam.res: 720x480; Len: 20m
Type of meter: inspection camera
Kind of display used: LCD 7"
Camera resolution: 720x480
IP rating: IP68
Measuring instrument features: AVI recording format; LED for measurement spot illumination; meter markers on video cable; option of memory card connection SD; TV-Out (NTSC)
Standard equipment: battery charger/power supply; hard case; sunshield
Battery/ rechargeable battery: rechargeable battery Li-Ion 12V 4400mAh
Plug variant: EU
Manufacturer series: AX-B21XX
Probe diameter: 23mm
Cable length: 20m

Виробник: AXIOMET
Category: Inspection Cameras, Boroscopes
Description: Inspection camera; Display: LCD 7"; Cam.res: 720x480; Len: 20m
Type of meter: inspection camera
Kind of display used: LCD 7"
Camera resolution: 720x480
IP rating: IP68
Measuring instrument features: LED for measurement spot illumination; meter markers on video cable
Standard equipment: battery charger/power supply; hard case; sunshield
Battery/ rechargeable battery: rechargeable battery Li-Ion 12V 4400mAh
Plug variant: EU
Manufacturer series: AX-B21XX
Probe diameter: 23mm
Cable length: 20m

Виробник: AXIOMET
Category: Inspection Cameras, Boroscopes
Description: Inspection camera; Display: LCD 7"; Cam.res: 720x480; Len: 35m
Type of meter: inspection camera
Kind of display used: LCD 7"
Camera resolution: 720x480
IP rating: IP68
Measuring instrument features: LED for measurement spot illumination; meter markers on video cable
Standard equipment: battery charger/power supply; hard case; sunshield
Battery/ rechargeable battery: rechargeable battery Li-Ion 12V 4400mAh
Plug variant: EU
Manufacturer series: AX-B21XX
Probe diameter: 23mm
Cable length: 35m

Виробник: AXIOMET
Category: Inspection Cameras, Boroscopes
Description: Inspection camera; Display: LCD 3,5"; Cam.res: 640x480; Len: 1m
Type of meter: inspection camera
Kind of display used: LCD 3,5"
Display resolution: 320x240
Probe diameter: 12mm
Operating temperature: 0...45°C
Power supply: battery LR6 AA 1,5V x4
Interface: USB
Measuring instrument features: automatic power-off; date and time setting possibility; digital zoom x4; flexible cord; LED for measurement spot illumination; option of memory card connection SD; TV-Out (PAL/NTSC)
Standard equipment: fixtures: mirror, hook, magnet; USB cable; video cable
Dimensions: 270x75x100mm
IP rating: IP67
Battery/ rechargeable battery: none
Software: included
Memory capacity: 64Mb
Camera resolution: 640x480
Related items: AX-BCX2; AX-BCX3
Supported formats: AVI; JPEG
Cable length: 1m

Виробник: AXIOMET
Category: Inspection Cameras, Boroscopes
Description: Extension cable for inspection camera; Len: 3m; Probe dia: 17mm
Type of test accessories: extension cable for inspection camera
Related items: AX-B250
Probe diameter: 17mm
Cable length: 3m

Виробник: AXIOMET
Category: Inspection Cameras, Boroscopes
Description: Probe: for inspection camera; Len: 1m; Probe dia: 6mm
Related items: AX-B250
Probe diameter: 6mm
Cable length: 1m
Type of measuring probe: for inspection camera

Виробник: AXIOMET
Category: Inspection Cameras, Boroscopes
Description: Camera head; 23mm; AX-B2120CW,AX-B2120RD,AX-B2120ST
Related items: AX-B2120CW; AX-B2120RD; AX-B2120ST
Type of test accessories: camera head
Probe diameter: 23mm

Виробник: AXIOMET
Category: Inspection Cameras, Boroscopes
Description: Extension cable for inspection camera; Len: 3m; Probe dia: 12mm
Related items: AX-B150; AX-B350
Cable length: 3m
Type of test accessories: extension cable for inspection camera
Probe diameter: 12mm

Виробник: AXIOMET
Category: Inspection Cameras, Boroscopes
Description: Probe: for inspection camera; Len: 1m; Probe dia: 9mm
Related items: AX-B150; AX-B350
Application: AX-B150; AX-B350
Probe diameter: 9mm
Cable length: 1m
Type of measuring probe: for inspection camera

Виробник: AXIOMET
Category: Gas Meters and Loggers
Description: Meter: CO2, temperature and humidity; Range: 300÷3000ppm ( CO2)
Supply voltage: 5V DC
Measuring range: 300...3000ppm ( CO2)
Humidity measuring range: 0...100% RH
Interface: USB
Kind of display used: LCD
IP rating: IP40
Humidity measuring accuracy: ±3%
Measuring instrument features: 3 level psychological comfort indicator (temperature/humidity); acoustic and optical alarm; date and time setting possibility; holder for wall mounting or desktop placing; HOLD function; MIN/MAX function; overflow indicator; relay output
Type of meter: CO2, temperature and humidity
Dimensions: 125x85x30mm
Internal temperature measuring range: -20...50°C
Measuring unit: °C; °F
Illumination: yes
Plug variant: EU
Bargraph: yes
Measurement: CO₂; humidity; temperature
Measurement accuracy: ±(50ppm+3%)
Temperature measurement accuracy: ±0.5°C

Виробник: AXIOMET
Category: Calibrators
Description: Meter: calibrator; loop; VDC: 0÷28V; I DC: 0÷22mA; 0÷50°C; 1mVDC
Type of meter: calibrator
Measurement: 0-20mA current loop; DC current; DC voltage
Kind of display used: LCD
Display parameters: 4,5 digit (19999)
DC voltage measuring range: 0...28V
DC current measuring range: 0...22mA
DC current measuring accuracy: ±(0.02% + 4µA)
Operating temperature: 0...50°C
Dimensions: 180x90x47mm
Power supply: battery LR6 AA 1,5V x2
Conform to the norm: CAT IV 600V; EN 61010
Measuring instrument features: 24V loop supply voltage; automatic power-off; low battery indicator; tests in 25% steps and at 100% of signal
Battery/ rechargeable battery: none
Current measuring resolution: 1µA
Voltage measuring resolution: 1mV DC
Current source: 0...22mA
Kind of calibrator: loop

Виробник: AXIOMET
Category: Calibrators
Description: Meter: calibrator; loop; VDC: 0÷50V; VDC accuracy: ±(0.5%+4digit)
Type of meter: calibrator
Kind of calibrator: loop
Kind of display used: LCD
Display parameters: (5000)
DC voltage measuring range: 0...50V
DC voltage measuring accuracy: ±(0.5% + 4 digit)
AC voltage measuring range: 0...500V
AC voltage measuring accuracy: ±(1.5% + 4 digit)
DC current measuring range: 0...20mA
DC current measuring accuracy: ±(0.2% + 4 digit)
Resistance measuring range: 5kΩ
Resistance measuring accuracy: ±(0.5%+4 digit)
Current source: 0...20mA
Test: diodes
Continuity test: acoustic indication
Operating temperature: 0...40°C
Dimensions: 180x90x47mm
Power supply: battery LR6 AA 1,5V x2
Measuring instrument features: 24V loop supply voltage; automatic power-off; HART range with loop and built-in 250Ω resistor; HOLD function; measure, source and simulate current in mA; source and simulate 0-20mA or 4-20mA output signal; tests in 25% steps and at 100% of signal
Measurement: AC voltage; DC current; DC voltage; resistance
Conform to the norm: CAT IV 600V; EN 61010
Sampling: 2,5x/s
Battery/ rechargeable battery: none

Виробник: AXIOMET
Category: Calibrators
Description: Spare part: motherboard; AX-C800
Type of spare part: motherboard
Related items: AX-C800

Виробник: AXIOMET
Category: Calibrators
Description: Meter: calibrator; voltage,current; VDC: 0÷100mV,10V; I DC: 0÷24mA
Type of meter: calibrator
Measurement: DC current; DC voltage
Kind of display used: LCD
DC voltage measuring range: 0...100mV; 10V
DC voltage measuring accuracy: ±(0.02% + 2 digit)
DC current measuring range: 0...24mA
DC current measuring accuracy: ±(0.015% + 2 digit)
Dimensions: 204x99x46mm
Power supply: battery GR03 AAA 1,5V x6
Standard equipment: case; insulated crocodile clips; set of test leads with probes
Protection: anti-overload OPP; anti-overvoltage OVP
Resistance to: fall from 1m height
Measuring instrument features: 24V loop supply voltage; measurement and sourcing of current in mA and A; measurement or generation of voltage in mV and V; simultaneous readout in mA and % of range
Battery/ rechargeable battery: battery GR03 AAA 1,5V x6
Illumination: yes
Current source: 0...24mA
Voltage source: 0...100mV; 0...10V
Kind of calibrator: current; voltage
Current source accuracy: ±(0,015% + 2 digits)
Voltage source accuracy: ±(0,02% + 2 digits)

Виробник: AXIOMET
Category: Calibrators
Description: Meter: calibrator; thermocouple; ±(0.025%+2digit); Unit: °C,°F
Kind of display used: LCD
Power supply: battery GR03 AAA 1,5V x6
Illumination: yes
Measuring unit: °C; °F
Dimensions: 205x98x46mm
Standard equipment: case; K-terminal
Measuring instrument features: high accuracy; impact resistant holster; measures and simulates; operates with thermocouple types: J, K, T, E, R, S, B, N; power supply socket
Type of meter: calibrator
Temperature measuring range (with K-type thermocouple): -200...1370°C
Temperature measuring range (with J-type thermocouple): -200...1200°C
Temperature measuring range (with T-type thermocouple): -200...400°C
Temperature measuring range (with R-type thermocouple): -20...1750°C
Temperature measuring range (with S-type thermocouple): -20...1750°C
Temperature measuring range (with E-type thermocouple): -200...950°C
Temperature measuring range with N-type thermocouple: -250...1300°C
Kind of calibrator: thermocouple
Measurement: temperature
Battery/ rechargeable battery: battery GR03 AAA 1,5V x6
Display parameters: 5 digits
DC voltage measuring accuracy: ±(0.025% + 2 digit)

Виробник: AXIOMET
Category: Calibrators
Description: Meter: calibrator; RTD; R range: 10mΩ÷400Ω,1.5kΩ,3.2kΩ
Type of meter: calibrator
Kind of display used: LCD
Power supply: battery GR03 AAA 1,5V x6
Measuring instrument features: low battery indicator; measures by means of 2-, 3- or 4-wire method; operates with 7 types of RTDs: Pt10 (385), Pt50, Pt100, Pt200, Pt500, Pt1000, Pt100 (JIS); output signal simulation
Standard equipment: case; insulated crocodile clips; test leads
Measurement: resistance
Measuring unit: °C; °F
Dimensions: 205x98x46mm
Battery/ rechargeable battery: battery GR03 AAA 1,5V x6
Illumination: yes
Resistance measuring range: 10mΩ...400Ω; 1.5kΩ; 3.2kΩ
Resistance measuring accuracy: ±100mΩ(100mΩ...400Ω); ±500mΩ(400Ω...1.5kΩ); ±1Ω(1500Ω...3200Ω)
Resistance to: fall from 1m height
Kind of calibrator: RTD
RTDs measurement and simulation: range: -200...630°C (Pt100 JIS, Pt200, Pt500, Pt1000, ±0,2°C accuracy); range: -200...800°C (Pt10, Pt50, Pt100, ±0,33°C accuracy); resolution: 0,1°C; maximal voltage: 30V

Виробник: AXIOMET
Category: Probes - Test Plugs
Description: Probe tip; 10A; red and black; Tip diameter: 2mm; Socket size: 4mm
Type of test accessories: measuring tip
Current rating: 10A
Colour: red and black
Tip diameter: 2mm
Socket size: 4mm
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Overall length: 123mm

Виробник: AXIOMET
Category: Test hooks
Description: Clip-on probe; with puncturing point; 10A; black; 4mm; Ø: 4mm
Type of test accessories: clip-on probe
Current rating: 10A
Colour: black
Insulator material: polyamide
Conform to the norm: CAT III 1000V; EN 61010
Contact material: brass/steel
Socket size: 4mm
Overall length: 136mm
Kind of clip-on probe: with puncturing point
Max. wire diameter: 4mm

Виробник: AXIOMET
Category: Test hooks
Description: Clip-on probe; with puncturing point; 10A; red; 4mm; Ø: 4mm
Type of test accessories: clip-on probe
Current rating: 10A
Colour: red
Insulator material: polyamide
Conform to the norm: CAT III 1000V; EN 61010
Contact material: brass/steel
Socket size: 4mm
Overall length: 136mm
Kind of clip-on probe: with puncturing point
Max. wire diameter: 4mm

Виробник: AXIOMET
Category: Test hooks
Description: Clip-on probe; with puncturing point; 10A; black; 4mm
Type of test accessories: clip-on probe
Kind of clip-on probe: with puncturing point
Grip capacity: max. 6mm
Socket size: 4mm
Colour: black
Contact plating: nickel plated
Insulator material: polyamide
Current rating: 10A
Contact material: brass/steel
Conform to the norm: CAT III 1000V; EN 61010
Overall length: 159mm

Виробник: AXIOMET
Category: Test hooks
Description: Clip-on probe; with puncturing point; 10A; red; 4mm
Type of test accessories: clip-on probe
Kind of clip-on probe: with puncturing point
Grip capacity: max. 6mm
Socket size: 4mm
Colour: red
Contact plating: nickel plated
Insulator material: polyamide
Current rating: 10A
Contact material: brass/steel
Conform to the norm: CAT III 1000V; EN 61010
Overall length: 159mm

Виробник: AXIOMET
Category: Probes - Test Plugs
Description: Probe tip; 10A; black; Tip diameter: 2mm; Socket size: 4mm
Type of test accessories: measuring tip
Current rating: 10A
Colour: black
Tip diameter: 2mm
Socket size: 4mm
Conform to the norm: CAT II 1000V; EN 61010
Overall length: 103mm
Insulator material: polyamide

Виробник: AXIOMET
Category: Probes - Test Plugs
Description: Probe tip; 10A; red; Tip diameter: 2mm; Socket size: 4mm
Type of test accessories: measuring tip
Current rating: 10A
Colour: red
Tip diameter: 2mm
Socket size: 4mm
Conform to the norm: CAT II 1000V; EN 61010
Overall length: 103mm
Insulator material: polyamide

Виробник: AXIOMET
Category: Test hooks
Description: Clip-on probe; pincers type; 2A; 60VDC; black; Grip capac: max.2mm
Type of test accessories: clip-on probe
Kind of clip-on probe: pincers type
Grip capacity: max. 2mm
Socket size: 0.64mm
Colour: black
Contact plating: gold-plated
Insulator material: polyamide
Rated voltage: 60V DC
Current rating: 2A
Contact material: brass
Overall length: 51mm

Виробник: AXIOMET
Category: Test hooks
Description: Clip-on probe; pincers type; 2A; 60VDC; red; Grip capac: max.2mm
Type of test accessories: clip-on probe
Kind of clip-on probe: pincers type
Grip capacity: max. 2mm
Socket size: 0.64mm
Colour: red
Contact plating: gold-plated
Insulator material: polyamide
Rated voltage: 60V DC
Current rating: 2A
Contact material: brass
Overall length: 51mm

Виробник: AXIOMET
Category: Test hooks
Description: Clip-on probe; pincers type; 10A; black; Grip capac: max.4mm; 4mm
Type of test accessories: clip-on probe
Current rating: 10A
Colour: black
Insulator material: polyamide
Conform to the norm: CAT II 1000V; EN 61010
Contact material: brass
Grip capacity: max. 4mm
Socket size: 4mm
Overall length: 155mm
Kind of clip-on probe: pincers type

Виробник: AXIOMET
Category: Test hooks
Description: Clip-on probe; pincers type; 10A; red; Grip capac: max.4mm; 4mm
Type of test accessories: clip-on probe
Current rating: 10A
Colour: red
Insulator material: polyamide
Conform to the norm: CAT II 1000V; EN 61010
Contact material: brass
Grip capacity: max. 4mm
Socket size: 4mm
Overall length: 155mm
Kind of clip-on probe: pincers type

Виробник: AXIOMET
Category: 4mm Crocodile Clips
Description: Crocodile clip; 5A; red and black; Overall len: 55mm; Thread: M4
Type of test accessories: crocodile clip
Current rating: 5A
Colour: red and black
Overall length: 55mm
Insulator material: PVC
Related items: AX-TLS-007S
Max jaw capacity: 8mm
Test accessories features: threaded
Thread: M4

Виробник: AXIOMET
Category: 4mm Crocodile Clips
Description: Crocodile clip; 5A; red and black; Socket size: 4mm
Type of test accessories: crocodile clip
Current rating: 5A
Colour: red and black
Socket size: 4mm
Overall length: 55mm
Insulator material: PVC
Max jaw capacity: 8mm

Виробник: AXIOMET
Category: 2mm Crocodile Clips
Description: Crocodile clip; 10A; 60VDC; black; Overall len: 41.5mm
Type of test accessories: crocodile clip
Current rating: 10A
Colour: black
Overall length: 41.5mm
Grip capacity: max. 8.5mm
Contact plating: nickel plated
Contact material: brass
Insulator material: polyamide
Socket size: 2mm
Rated voltage: 60V DC

Виробник: AXIOMET
Category: 2mm Crocodile Clips
Description: Crocodile clip; 10A; 60VDC; blue; Overall len: 41.5mm
Type of test accessories: crocodile clip
Current rating: 10A
Colour: blue
Overall length: 41.5mm
Grip capacity: max. 8.5mm
Contact plating: nickel plated
Contact material: brass
Insulator material: polyamide
Socket size: 2mm
Rated voltage: 60V DC

Виробник: AXIOMET
Category: 2mm Crocodile Clips
Description: Crocodile clip; 10A; 60VDC; green; Overall len: 41.5mm
Type of test accessories: crocodile clip
Current rating: 10A
Colour: green
Overall length: 41.5mm
Grip capacity: max. 8.5mm
Contact plating: nickel plated
Contact material: brass
Insulator material: polyamide
Socket size: 2mm
Rated voltage: 60V DC

Виробник: AXIOMET
Category: 2mm Crocodile Clips
Description: Crocodile clip; 10A; 60VDC; red; Overall len: 41.5mm
Type of test accessories: crocodile clip
Current rating: 10A
Colour: red
Overall length: 41.5mm
Grip capacity: max. 8.5mm
Contact plating: nickel plated
Contact material: brass
Insulator material: polyamide
Socket size: 2mm
Rated voltage: 60V DC

Виробник: AXIOMET
Category: 2mm Crocodile Clips
Description: Crocodile clip; 10A; 60VDC; yellow; Overall len: 41.5mm
Type of test accessories: crocodile clip
Current rating: 10A
Colour: yellow
Overall length: 41.5mm
Grip capacity: max. 8.5mm
Contact plating: nickel plated
Contact material: brass
Insulator material: polyamide
Socket size: 2mm
Rated voltage: 60V DC

Виробник: AXIOMET
Category: 4mm Crocodile Clips
Description: Crocodile clip; 15A; black; Grip capac: max.12mm; Socket size: 4mm
Type of test accessories: crocodile clip
Current rating: 15A
Colour: black
Grip capacity: max. 12mm
Socket size: 4mm
Conform to the norm: CAT II 300V; EN 61010
Overall length: 56mm
Contact plating: nickel plated
Contact material: brass
Insulator material: polyamide

Виробник: AXIOMET
Category: 4mm Crocodile Clips
Description: Crocodile clip; 15A; blue; Grip capac: max.12mm; Socket size: 4mm
Type of test accessories: crocodile clip
Current rating: 15A
Colour: blue
Grip capacity: max. 12mm
Socket size: 4mm
Conform to the norm: CAT II 300V; EN 61010
Overall length: 56mm
Contact plating: nickel plated
Contact material: brass
Insulator material: polyamide

Виробник: AXIOMET
Category: 4mm Crocodile Clips
Description: Crocodile clip; 15A; green; Grip capac: max.12mm; Socket size: 4mm
Type of test accessories: crocodile clip
Current rating: 15A
Colour: green
Grip capacity: max. 12mm
Socket size: 4mm
Conform to the norm: CAT II 300V; EN 61010
Overall length: 56mm
Contact plating: nickel plated
Contact material: brass
Insulator material: polyamide

Виробник: AXIOMET
Category: Coating Thickness Testers
Description: Tester: coating thickness; Range: 10÷1250um; 80x42x24mm
Type of tester: coating thickness
Measuring range: 10...1250µm
Measurement accuracy: ±2% ±0,02mm
Power supply: battery CR2032 3V x1
Body dimensions: 80x42x24mm
Measuring instrument features: automatic power-off; HOLD function; low battery indicator

Виробник: AXIOMET
Category: Generators and Frequency Meters
Description: Software; Equipment: RS232 cable; Software: included
Type of test accessories: software
Standard equipment: RS232 cable
Related items: AX-DG105
Software: included

Виробник: AXIOMET
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 5MHz; LCD TFT 3,5"; Ch: 2; 1024pts
Type of generator: arbitrary, function
Maximum waveform frequency: 5MHz
Waveform frequency range: 1µHz...1MHz (other waveforms); 1µHz...1MHz (ramp waveform); 1µHz...1MHz (triangle waveform); 1µHz...5MHz (rectangular waveform); 1µHz...5MHz (sinus waveform)
Kind of display used: LCD TFT 3,5"
Number of channels: 2
Amplitude: value of amplitude Vpp<0,2V - actual offset value is 1% of set value; value of amplitude Vpp>2V - actual offset value is set value; value of amplitude Vpp 0,2...2V - actual offset value is 10 % of set value
Memory record length: 1024pts
Vertical resolution: 8bit
Output parameters: impedance: 50Ω
Sweep mode: period: 100m...900s
Dimensions: 415x295x195mm
Interface: RS232
Kind of modulation: ASK; FM; FSK; PSK
Waveforms: arbitrary; ramp; rectangular; sinus; triangle
Sampling: 100Msps
Plug variant: EU
Protection: against reverse polarity; anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Additional functions: frequency meter
Standard equipment: BNC cable; mains cable; RS232 cable; test lead
Measuring instrument features: 32 built-in waveforms
Software: included
Supply voltage: 100...240V AC

Виробник: AXIOMET
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 15MHz; LCD TFT 3,5"; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 15MHz
Waveform frequency range: 1µHz...1MHz (other waveforms); 1µHz...1MHz (ramp waveform); 1µHz...1MHz (triangle waveform); 1µHz...5MHz (rectangular waveform); 1µHz...15MHz (sinus waveform)
Kind of display used: LCD TFT 3,5"
Number of channels: 2
Amplitude: value of amplitude Vpp 0,2...2V - actual offset value is 10 % of set value; value of amplitude Vpp<0,2V - actual offset value is 1% of set value; value of amplitude Vpp>2V - actual offset value is set value
Memory record length: 1024pts
Vertical resolution: 8bit
Output parameters: impedance: 50Ω
Sweep mode: period: 100m...900s
Dimensions: 415x295x195mm
Interface: RS232
Kind of modulation: ASK; FM; FSK; PSK
Waveforms: arbitrary; ramp; rectangular; sinus; triangle
Sampling: 100Msps
Plug variant: EU
Protection: against reverse polarity; anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Additional functions: frequency meter
Standard equipment: BNC cable; mains cable; RS232 cable; test lead
Measuring instrument features: 32 built-in waveforms
Software: included
Supply voltage: 100...240V AC

Виробник: AXIOMET
Category: Generators and Frequency Meters
Description: Generator: function; 5MHz; LCD; Ch: 2; 1024pts; Vert.resol: 8bit
Type of generator: function
Maximum waveform frequency: 5MHz
Waveform frequency range: 1µHz...1MHz (other waveforms); 1µHz...1MHz (ramp waveform); 1µHz...1MHz (triangle waveform); 1µHz...5MHz (rectangular waveform); 1µHz...5MHz (sinus waveform)
Kind of display used: LCD
Number of channels: 2
Memory record length: 1024pts
Vertical resolution: 8bit
Output parameters: impedance: 50Ω
Sweep mode: period: 100m...900s
Dimensions: 415x295x195mm
Kind of modulation: ASK; FM; FSK; PSK
Sampling: 100Msps
Plug variant: EU
Protection: against reverse polarity; anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Additional functions: frequency meter
Optional equipment: AX-DG100-SOF software
Standard equipment: BNC cable; mains cable; test lead
Measuring instrument features: 32 built-in waveforms
Supply voltage: 100...240V AC

Виробник: AXIOMET
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 10MHz; Ch: 2; 16kpts/ch; Plug: EU
Interface: USB
Waveform frequency range: 1µHz...10MHz (rectangular waveform); 1µHz...10MHz (sinus waveform); 1µHz...300kHz (ramp waveform); 1µHz...300kHz (triangle waveform); 500µHz...5MHz (pulse waveform)
Rectangular waveform parameters: rise/fall time: <12ns
Sweep mode: period: 1m...500s
Output parameters: impedance: 50Ω
Vertical resolution: 14bit
Kind of modulation: AM; ASK; FM; FSK; PM; PSK
Plug variant: EU
Waveforms: arbitrary; impulse; noise; ramp; rectangular
Maximum waveform frequency: 10MHz
Software: included
Memory record length: 16kpts/ch
Supply voltage: 100...240V AC
Type of generator: arbitrary, function
Number of channels: 2
Dimensions: 105x281x229mm
Standard equipment: mains cable; USB cable
Sampling: 125Msps

Виробник: AXIOMET
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 50MHz; 500Msps (in real time); 7ns
Standard equipment: mains cable; oscilloscope probe (1 per channel); USB cable
Display resolution: 800x480
Input impedance: 1MΩ/18pF
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; digital filter function; displays input waveform and FFT on divided screen; integrated FFT with algorithm selection: Hamming, Hanning, Blackman, Rectangular; mathematical functions: addition, subtraction, division, multiplication and FFT; Pass/Fail function
Sampling: 500Msps (in real time)
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; risetime; rising-edge; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2; external signal; supply voltage source
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 400V
Plug variant: EU
Band: 50MHz
Rise time: 7ns
Input sensitivity: 2mV/div...10V/div
Time base: 5n...50s/div
Supply voltage 400Hz: 100...120V AC
Memory record length: 32kpts
Kind of display used: LCD TFT 7"
Supply voltage: 100...240V AC
Body dimensions: 323.1x135.6x157mm
Interface: LAN; USB
Number of channels: 2

Виробник: AXIOMET
Category: Temperature and Humidity Loggers
Description: Data logger; temperature,humidity; ±3.5%; Temp: -40÷70°C; 115g
Body dimensions: 94x48x33mm
Interface: USB
Kind of output connector: USB B socket
Measuring unit: °C; °F
Measurement memory: 16350
Standard equipment: mounting holder; USB cable
Measuring instrument features: date and time setting possibility; LED status indicator; low battery indicator; memory overflow indicator; sampling period: 2s, 5s, 10s, 30s, 1min., 5min., 10min., 30min., 1h, 2h, 3h, 6h, 12h, 24h; settable MIN/MAX alarm thresholds
Type of meter: data logger
Weight with battery: 115g
Temperature measurement resolution: 0.1°C
Humidity measuring accuracy: ±3.5%
Temperature measuring range: -40...70°C
Humidity measuring range: 0...100% RH
Humidity measuring resolution: 0.1% RH
Measurement: humidity; temperature
Battery/ rechargeable battery: none
Software: included
Temperature measurement accuracy: ±1°C @(-10°C...40°C); ±2°C @(-40°C...-10°C); ±2°C @(40°C...70°C)
Kind of display used: LCD
Power supply: battery 1/2AA 3,6V x1

Виробник: AXIOMET
Category: Electronic Loads
Description: Electronic load; 0÷150V; 0.001÷30A; 150W; 215x89x412mm
Type of meter: electronic load
Operating current: 0.001...30A
Maximum power: 150W
Dimensions: 215x89x412mm
Kind of display used: LCD 4,3"
Interface: RS232
Operating modes: constant current; constant power; constant resistance; constant voltage
Standard equipment: mains cable; RS232-USB cable
Protection: against reverse polarity; anti-overvoltage OVP; over current OCP; overheating OTP
Operating voltage: 0...150V
Illumination: yes
Supply voltage: 100...240V AC

Виробник: AXIOMET
Category: Electronic Loads
Description: Electronic load; 0÷150V; 0.001÷30A; 300W; 215x89x412mm
Supply voltage: 100...240V AC
Protection: against reverse polarity; anti-overvoltage OVP; over current OCP; overheating OTP
Operating current: 0.001...30A
Interface: RS232
Maximum power: 300W
Illumination: yes
Operating modes: constant current; constant power; constant resistance; constant voltage
Dimensions: 215x89x412mm
Standard equipment: mains cable; RS232-USB cable
Type of meter: electronic load
Kind of display used: LCD 4,3"
Operating voltage: 0...150V

Виробник: AXIOMET
Category: Electronic Loads
Description: Electronic load; 0÷150V; 0.001÷60A; 300W; 215x89x412mm
Supply voltage: 100...240V AC
Protection: against reverse polarity; anti-overvoltage OVP; over current OCP; overheating OTP
Kind of display used: LCD 4,3"
Operating current: 0.001...60A
Operating modes: constant current; constant power; constant resistance; constant voltage
Dimensions: 215x89x412mm
Maximum power: 300W
Interface: RS232
Illumination: yes
Type of meter: electronic load
Operating voltage: 0...150V
Standard equipment: mains cable; RS232-USB cable

Виробник: AXIOMET
Category: Luxmeters
Description: Light meter; 41segm; 40/400/4k/40k/400klx,40/400/4k/40kFc; 280g
Type of meter: light meter
Kind of display used: LCD
Measuring range: 40/400/4k/40k/400klx; 40/400/4k/40kFc
Power supply: battery 6F22 9V x1
Dimensions: 203x75x50mm
Standard equipment: case
Measuring instrument features: automatic power-off; autozeroing; cosine correction; HOLD function; light sensor on 1,5m long cable; MIN/MAX/REL function; PEAK HOLD function; reinforced enclosure
Illumination: yes
Battery/ rechargeable battery: battery 6F22 9V x1
Bargraph: 41 segm.
Display parameters: 3,75 digit (3999)
Measurement accuracy: ±(5% of readout + 10 digits)
Weight without batteries: 280g
Sampling: 1,5x/s

Виробник: AXIOMET
Category: LCR Meter
Description: LC meter; LCD; (1999); 2nF,200nF,2uF,20uF,200uF,500uF; 2mH÷20H
Type of meter: LC meter
Kind of display used: LCD
Capacitance measuring range: 2nF; 200nF; 2µF; 20µF; 200µF; 500µF
Capacitance measuring accuracy: ±(1% + 5 digits)
Inductance measuring range: 2mH...20H
Power supply: battery 6F22 9V x1
Standard equipment: adapter for connecting K-type probe to the meter; test leads
Measurement: capacitance; inductance
Body dimensions: 190x88.5x27.5mm
Inductance measuring accuracy: ±(2% + 5 digits)
Display parameters: (1999)
Illumination: yes
Measurement frequency: 100Hz; 1kHz

Виробник: AXIOMET
Category: LCR Meter
Description: LCR meter; LCD; 20÷200MΩ; 0.1÷9999000000pF; C accuracy: ±0.3%
Type of meter: LCR meter
Kind of display used: LCD
Resistance measuring range: 20...200MΩ
Capacitance measuring range: 0.1pF...9999µF
Capacitance measuring accuracy: ±0.3%
Inductance measuring accuracy: ±0.3%
Resistance measuring accuracy: ±0.3%
Measurement frequency: 100Hz; 120Hz; 1kHz; 10kHz; 100kHz
Measurement: capacitance; dissipation factor D; inductance; phase angle θ; quality factor Q; resistance
Inductance measuring range: 20mH...20kH
Illumination: yes
Battery/ rechargeable battery: battery GR03 AAA 1,5V x6
Power supply: battery GR03 AAA 1,5V x6; mains power supply
Measuring instrument features: automatic power-off; calibration function; HOLD function; parallel or serial measurement; REL function; selectable parallel or serial equivalent circuit
Standard equipment: four-wire Kelvin clips
Bargraph: yes
